Introduction of frozen french fries production line:
1. We offer turn key project of frozen french fries production line from capacity to 50kg per hour to 2000kg per hour.
2. It is more convenient to operate, adjustable and low broken rate, reduces
labor time but raises output.
3, We have rich experience on frozen french fries production line. Now our line has been installed in KSA, Algeria, tunis, Morocco,Zambia and so on.
No |
Project |
Contents |
Remarks |
1 |
Capacity |
2000Kg/h |
Fresh OKRA |
2 |
Processing time |
10-100min adjustable |
Manual operation & frequency control |
3 |
Feeding temperature |
Room temperature |
|
4 |
Width of conveyor belt |
750mm/650mm/1300mm |
Wire belt / food grade PVC belt / quick-freezing machine belt |
5 |
Blanching temperature |
80-100°C adjustable |
Using screw peel and blanching |
6 |
blanching required steam |
1.0 T/h |
(0.4-0.7)Mpa |
7 |
Air cooled |
room temperature cooling & freezing cooling |
|
8 |
gas consumption for fryer |
25~35L/H |
gas |
9 |
Water consumption |
Water supply first time around 20T |
Sink water supply |
10 |
Water consumption |
About 5.0T/h |
Mainly engaged in washing and peeling |
11 |
Installed power |
284Kw |
380V/50HZ |
12 |
Workshop space |
50meters in length and 10meters in width |
|
13 |
Number of operators |
6-7 peoples |
|
1. process
okra——de-stoner&cleaning——washing——inspecting——cutting——grading——blanching——conditioning——pre-cooling ——frozen——packing ——cold storage
2.Capacity (50kg per hour to 2000kg per hour for choosing)
