Help CenterSoda Water Breath Frozen Self-supporting Bag Filling Capping Machines
Related Products
-
500L Concial Beer Yogurt Fermentation Tank With Cooling JacketNegotiableMOQ: 1 -
Board Belt Tunnel Freezer IQF Machine(Individual Quick Freezer)NegotiableMOQ: 1
-
Vegetable & Fruit&Seafood IQF Tunnel Quick FreezerNegotiableMOQ: 1
-
SSD Series IQF Quick Freezing Refrigeration SystemNegotiableMOQ: 1
-
Tunnel Quick Freezer Price/quick Freezing TunnelNegotiableMOQ: 1
FEATURES
Multi-application---Separated-type feeding system, can meet many various kinds of materials(powder, liquid or paste etc.)
Multi-shapes bags---After simple adjustment, one machine can meet many different kinds of bags(3-sides seal, 4-sides seal,stand-up pouch(doypack),zipper bag,nozzle bag etc. )
Multi-materials---Particular feeding system, have overcome the shortcomings of general packing machines sole materials, it can meet many kinds of different materials mixtures, and precise proportion(e.g. with oil,water or others etc.)
Operation Stability---Adopting cam for transmission, pure mechanical motions, simple structure.
Easy to maintenance---Simple mechanical structure, easy to maintenance
Low Failure Rate---In compared to Pure Mechanical Packing Machine, no very many control element and test elements, which can avoid electronic errors.
Beautiful Outlook—-Unique,Advanced and Mature technology,finished bags flat, without leakage.
Reducing Loss—-High precise packing, can reduce materials loss
Good Reliability---All of the ELECTRIC ELEMENTS are international famous brand, good quality&reliability
Item |
Parameter |
|
Packing |
Pouch size range |
60-80mm |
Pouch size range |
180-230mm |
|
Packing Capacity |
800ml(max) |
|
Packing Speed |
60bags/min(max) |
|
Specification |
Overall Size |
7800 (L) X1000 (W) X 1500 (H)mm(approx.) |
Total Weight |
2000Kg |
|
Working Environment |
Environment Temp. |
-10°C—+55°C |
Related Humidity |
<85%(No condensation state) |
|
Power Supply |
AC380V,50Hz |
|
Output Power |
6.5Kw |
|
Working Pressure |
0.5MPa |
|
Compressed-air Consumption |
0.6m3/min |
|
