Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing

Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing thumbnail-1
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing thumbnail-2
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing thumbnail-3
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing thumbnail-4
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing thumbnail-5
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing photo-1
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing photo-2
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing photo-3
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing photo-4
Shanghai Factory Industrial Plant Vacuum Freeze Dryer Equipment Drying Machine in Dried Fruit & Vegetable Processing photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2013
Factory Size:
Below 1,000 square meters
Contact Supplier Request Quote Chat Now
Shanghai Genyond Technology Co., Ltd.
Gold Verified Supplier
3Yrs
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description



Specification
Model
FZG-5
FZG-10
FZG-20
FZG-30
FZG-50
FZG-100
FZG-150
FZG-200
Effective drying area
㎡
5
10.5
20
30.1
50.31
98.68
148
197.4
Partition Size (L*W*H)
cm
100*100*2
150*100*2
200*100*1.5
214*54*1.8
310*54*1.8
608*54*1.8
912*54*1.8
1216*54*1.8
Partition quantity
pc
5+1
7+1
10+1
(13+1)*2
(15+1)*2
(15+1)*2
(15+1)*2
(15+1)*2
Partition spacing
mm
65
65
70
77
77
77
77
77
Number of trolleys (sUS304)
pc
/
/
/
1
2
4
6
8
Catching capacity
kg
100
200
400
600
800
1500
2000
3000
Partition operating temperature
℃
-45~+80
Minimum temperature of cold trap
℃
≤-65
Ultimate vacuum
Pa
≤2.7
Electric heating (option)
kW
9
16
24
12*3
16*3
24*4
48*3
32*6
Installed power
kW
40
63
90
125
150
290
380
570
Unit Dimensions (L*W*H)
m
4.5*2.1*3.6
6.3*2.1*3.6
7.6*2.1*3.6
7*2.5*3.6
9.1*2.5*3.6
15.7*2.5*3.6
25*2.5*3.6
29*2.5*3.6
Weight
ton
5
6.5
7.5
10
13.5
20
30
36
Detail Pictures
GENYOND MACHINERY INDUSTRIAL GROUP
It has 6 factories in China for food machine and packing machine.
Shanghai Genyond Technology Co Ltd; Zhangjiagang Genyond Machinery Co Ltd
Shanghai Jou Yu industrial Co Ltd; Shanghai Keyfood Machinery Co Ltd
Sino topone machinery; Nantong Yihai Machinery; Kunshan Kpack Machinery
Our products have been exported to more than 160 countries with Annual sales reaching 80 millions in 2022 and it raises by yearly average 10% above.
Genyond machine has more than 100 engineers for the installation of oversea projects.
You just need to give us your idea on final product to be made, processing capacity, way of packing, we will make the proposals for your checking. You can also give us your budget, we can also design a line to meet your budget accordingly. A satisfying project will be given; A long-term cooperation will come.
