Stainless Steel Refregeration Spiral Freezer for Pizza
Brief Introduction:
This spiral quick freezing machine is designed and manufactured in accordance with HACCP’s hygienic requirements for food processing equipments. It is suitable for fast freezing granular, diced, sliced food, including scallop, squid, de-shelled shrimp, fillet, etc. The food contact part is of solid stainless steel belt, which allows fast and efficient freezing.
Main Technical Parameter:
|
Item
Model |
Freezing capacity KG/H |
Freezing time min |
Refrigeration consumption kw |
Installed power kw |
Width of Belt m |
Overall dimension L×W×H m |
Circulating temperature in storehouse °C |
|
Single Layer Type |
|||||||
|
GY-100 |
100 |
3-60 |
35 |
10 |
1 |
7×1.5×2.1 |
-36±2 |
|
GY-500 |
300 |
3-60 |
70 |
17 |
1.3 |
10.4×3.0×2.5 |
-36±2 |
|
GY-500 |
500 |
3-60 |
130 |
18 |
1.3 |
12.4×3.6×2.5 |
-36±2 |
|
GY-1000 |
1000 |
3-60 |
186 |
22 |
1.8 |
14.9×3.6×2.5 |
-36±2 |
|
GY-1500 |
1500 |
6-80 |
256 |
25 |
2.5 |
16.9×3.6×2.5 |
-36±2 |
|
Double Layer Type |
|||||||
|
GY-600 |
600 |
3-60 |
91 |
13 |
1.8 |
11.2×4.4×2.3 |
-36±2 |
|
GY-1200 |
1200 |
3-60 |
175 |
20.6 |
2.2 |
16.9×3.6×2.5 |
-36±2 |
|
GY-1500 |
1500 |
3-60 |
225 |
28.4 |
2.2 |
16.9×3.6×2.5 |
-36±2 |
|
GY-2000 |
2000 |
6-80 |
296 |
39.6 |
2.2 |
16.9×3.6×2.5 |
-36±2 |
|
GY-3000 |
3000 |
6-80 |
440 |
40.4 |
3 |
19.9×3.6×2.5 |
-36±2 |
Other Details:
1.Package: wooden cases for sea transportation
2.Delivery time: 30 working days after receiving the deposit
3.Installation : engineers available for installation and training overseas
4.Guarantee : 12 months after it is sent out
