Description of mango and pineapple Processing Line
The pineapple production line processes fresh pineapple into clear and turbid juice, and the juice output is 50-75%.
technical parameter
Ingredients: fresh pineapple
Product: pure pineapple juice
Finished product packaging: sterile large bag / roof bag / Tetra Pak / PET bottle
Customer process: peeling, juicing, sterilization and filling
Pineapple juice production line process flow:
Pineapple → washing → peeling → slicing → juicing → filtering → mixing → homogenization → degassing → sterilization → filling → sealing → cooling → coding → finished product.
Flow chart of pineapple juice production line
Picking belt: the selection of raw materials requires no rotten fruits, no diseases and pests, and the maturity is 8-10%.
Cleaning machine: use bubble cleaning machine to remove pollutants on the stripped surface.
Head peeling machine: because the peel contains more protease and tannin, improper treatment will affect the product quality, so the peel must be removed manually
Slicer: cut pineapple into pieces for future use, which can increase the output of fruit juice;
Juicer: cut the peeled pineapple into small pieces and send it to the screw juicer for juicing. After the first extrusion, add a small amount of water, fully mix with apple pomace, and then squeeze again to increase the yield of fruit juice.
Belt Juicer: press the residue after juicing to improve the juice yield;
Butterfly separator: used for separating clear liquid and turbid liquid of pineapple juice;
Sterilization: instant sterilization is adopted for fruit juice sterilization, and the equipment adopts heat exchanger. The general condition is about 93 ° C and maintained for 20 seconds.
Filling machine: put the processed pineapple juice into aseptic barrels, which is convenient for transportation and has a long shelf life.
Condition: New
Brand name: Shanghai Genyond;
Type: whole processing Line/turnkey project/fruit and vegetables processing/dairy processing/beverage processing
Voltage: 220v/380v
Power(W): 100-200kw
Weight: Different size different weight/customized
Dimension(L*W*H): Different size different dimension/customized
Certification: CE&ISO
Warranty: 12 months/1 year
After-sales Service Provided: Engineers available to service machinery overseas
Main material: SUS304 or SUS316
Control type: automatic, semi-automatic
Energy consumption: Low consumption with high efficiency
Capacity: 500-10000L/H-customized
Installation period: 1-3months
Period time: 30 days-120 days
Cups material: pouches, paper box, glass bottle, pet bottle, glass bottle
Product storage condition: room temperature; low temperature;
Related machinery of fruit processing line
Fruit storage silo-- Washing, sorting machine-- Grading/classifier machine
Squeeze extractor--Juice refiner—separator—evaporator-- Juice concentrate product
Fruit flesh/pulp collector-sterilizer--filling machine—fruit flesh
Essential oil refiner—fruit oil
Fruit residues collector—animal feed
Soaking extraction, pre-cooking, pulping, quick freeze, stemmer, ultra-filtration, decolor, destoner, crusher, stone washer, brusher washer, pine apple extractor, refiner, enzymolysis, filtration, CIP cleaning system
