Fruit juice processing plant/ orange juice concentrate fruit production line
- 1000 per Month
- T/T Credit Card
You May Like
-
High Quality Fruit Juicer Machine/Commercial Juicer Machine/Fruit Juicer Production Line
-
centrifugal spray dryer
-
Pressure Spray Dryer/Fruit Juice Spray Dryer/instant coffee spray dryerwith factory price
-
Small capacity Ginkgo juice/fresh fruit juice production line /plant /processing line /equipment
-
Small capacity Hawthorn juice/fresh fruit juice production line /plant /processing line /equipment
-
date molasses production line
Product Description
Specifications
1.fruit juice production line
2.stainless steel
3.PLC control
4.high efficiency
Features:
This fruit juice processing plant can be used for making all kinds of fruit juice. All the equipments are made of 304 stainless steel which is durable and clean. All the standard connecting pipes are made of 304 stainless steel, customers can also choose PVC pipes. The whole system is full automatic. There is automatic electric control system. It just needs a few operators to handle the plant.
Main equipments:
juice extractor, water treatment plant, CIP cleaning system, sterilization machine, mixing tank, filling equipment.
Characteristics:
1. it can carry out washing pulp filling, liquid juice filling and capping in one machine.
2. it is very convenient to change diverse sizes of bottles by means of advanced bottle neck clamping & bottle suspending technology.
3. Advanced programmable PLC is equipped to control the main machine. Working speed can be adjusted by frequency conversion device.
Main Technical Data: apple juice production line | ||||||||
Model | CGF12125 | CGF18186 | CGF24248 | CGF323210 | CGF404012 | CGF505012 | CGF606015 | CGF808020 |
Number of washing, filling and capping heads | 12-12-5 | 18-18-6 | 24-24-8 | 32-32-10 | 40-40-12 | 50-50-12 | 60-60-15 | 80-80-20 |
Production capacity(600ml) (B/H) | 2000-4000 | 5000-7000 | 8000-12000 | 12000-15000 | 16000-20000 | 20000-24000 | 25000-30000 | 35000-40000 |
suitable bottle specification(mm) | φ=50-110=170 330-2250ml | |||||||
Washing pressure(kg/cm 2 ) | 2-3 | |||||||
Motor power(kw) | Main motor 2.2kw | Main motor 2.2kw | Main motor 3kw | Main motor 5.5kw | Main motor 7.5kw | Main motor 11kw | Main motor 15kw | Main motor 19kw |
Overall dimensions (mm) | 2400×1650 ×2500 | 2600×1920 ×2550 | 3100×2300 ×2800 | 3800×2800 ×2900 | 4600×2800 ×2900 | 5450×3300 ×2900 | 6500×4500 ×2900 | 76800×66400 ×2850 |
Weight (kg) | 2500 | 3500 | 4500 | 6500 | 8500 | 9800 | 12800 | 15000 |
Company Profile
Shanghai Genyond Technology Co., Ltd. is a manufacturer of extracting unit and fruit & vegetable processing line with well-equipped testing facilities and strong technical force.With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in food and beverage and other industries.Our products are widely recognized and trusted by users and can meet continuously changing economic and social needs.We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success!
