Factory Genyond Automatic High Pressure Juice Milk Homogenizer Homogenization Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Trading Company
Year Established:
2013
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Genyond Factory 1 Ton Per Hour Input Fruit Juice Production Line Mango Pineapple Processing PlantNegotiableMOQ: 1 -
Shanghai Genyond Factory Apple Grape Pineapple Wine Production LineNegotiableMOQ: 1
-
Genyond Factory Industrial Green Bean Pigeon Pea Peeling Equipment Peeling Machine PeelerNegotiableMOQ: 1
-
Factory Genyond Essential Oil Distiller Distillation Equipment Extractor Extracting MachineNegotiableMOQ: 1
-
Factory Genyond Mint Essential Oil Distiller Distillation Equipment Extractor Extracting MachineNegotiableMOQ: 1
Product Description
Specifications
1. It is cost-effective homogenizer
2. high pressure homogenizer
3. milk homogenize
high pressure milk homogenizer is a vertical layout, motor and gearbox installed within a rack, pump and connected to the gearbox.
Plunger is formed in the pump body movement suction and compression, will form a pressure the combination valve control solid to liquid, so as to achieve the loss of pressure, swelling, the combined effect of the explosion, shear and high-speed impact, crushing the particles and oil droplets in the liquid into a small size.
technical parameter
| Model | Capacity(m3/h) | Pressure(Mpa) | Diameter of inlet(mm) | Diameter of homegenizing (mm) |
outlet(mm) | Motor power (kw) |
Size (L×W×Hmm) |
Weight(kg) |
| GJB-1-25 | 1 | 25 | 25 | 15 | ZG1/2" | 7.5 | 1050x680x1110 | 600 |
| GJB-2-25 | 2 | 25 | 40 | 15 | ZG1/2" | 15 | 1150x930x1270 | 1000 |
| GJB-3-25 | 3 | 25 | 50 | 25 | ZG3/4" | 20 | 1250x1000x1350 | 1300 |
| GJB-4-25 | 4 | 25 | 50 | 25 | ZG3/4" | 23 | 1300x1160x1500 | 1400 |
| GJB-5-25 | 5 | 25 | 50 | 25 | ZG3/4" | 25 | 1400x1250x1600 | 1500 |
| GJB-1-40 | 1 | 40 | 25 | 15 | ZG1/2" | 15 | 1050x680x1110 | 1100 |
| GJB-2-40 | 2 | 40 | 40 | 15 | ZG1/2" | 22 | 1150x820x1180 | 1400 |
| GJB-3-40 | 3 | 40 | 50 | 25 | ZG3/4" | 30 | 1250x1150x1500 | 1700 |
| GJB-4-40 | 4 | 40 | 50 | 25 | ZG3/4" | 40 | 1300x1260x1600 | 2000 |
| GJB-5-40 | 5 | 40 | 25 | 25 | ZG3/4" | 50 | 1400x1360x1700 | 2300 |
| GJB-1-60 | 1 | 60 | 40 | 25 | ZG3/4" | 22 | 1300x1060x1350 | 1200 |
| GJB-2-60 | 2 | 60 | 50 | 25 | ZG3/4" | 38 | 1400x1160x1450 | 1500 |
| GJB-3-60 | 3 | 60 | 50 | 25 | ZG3/4" | 48 | 1500x1260x1550 | 1800 |
| GJB-5-60 | 5 | 60 | 50 | 25 | ZG3/4" | 68 | 1600x1360x1650 | 2100 |
