Help CenterDENOH Engine Welding Machine Power Generating Welder,HW450D Double Handle Digital Function Engine Welding Machine,Pipeline Welder,double Closed-loop Patented Technology
Related Products
-
DENOH Gas and Oil Pipeline Welder,Engine Welding Machine HW450D Double Handle Digital Function Engine Welding Machine,Pipeline Welder,NegotiableMOQ: 1 Unit -
DENOH Power Generator Welder, Digital Function Engine Welder Gas and Oil Pipeline Welder,Engine Welding Machine HW450D Double Handle Digital Function Engine Welding Machine,Pipeline Welder,NegotiableMOQ: 1 Unit
-
Engine Welding Machine,HW1000 Multi-function Welder,DENOH Engine Welder Diesel Power Generation Gas and Oil Pipeline Welder,Engine Welding Machine HW450D Double Handle Digital Function Engine Welding Machine,Pipeline Welder,NegotiableMOQ: 1 Unit
-
DENOH ENGINE WELDING MACHINE,HW1000 Diesel Generator Welding Machine,Mobile Power StationNegotiableMOQ: 1 Unit
-
DENOH Diesel Generator Welding Machine, ENGINE WELDING MACHINE,HW1000 ,Mobile Power StationNegotiableMOQ: 1 Unit
Simple instruction:
Welding and power generator integrated machine.Don’t need Engineering vehicle power station.
Easy to move .It is very suitable for matching our single torch automatic welding trolley and dual torch automatic welding trolley.Also can match wire feeder to realize semi-auto welding and all kinds of manual welding
Adavantages:
2.Cooperate with the DW series automatic welding trolley to get extremely optimized all position pipeline welding parameters and high-quality welding effect.
3.Can meet:
Single torch flux core welding;
Single torch pulse welding;
Single torch low splashing automatic root welding output;
Dual torch argon arc welding;
4.The main circuit topology adopts a Buck (chopping) topology structure
5.Adopting double closed-loop patented technology
6.Double torch current can be combined to single torch output, to meet the requirements of automatic welding;
7.Can meet usage of single/Dual torch argon arc welding,1set single torch automatic external welding and 15kW AC electric.
8.Adopting low spashing wave shape control technology,small splashing,stable weldpool,good weld consistency.
9.Adaptive arc length variation.
Insulation grade:H |
|||
Form.: Digital brushless |
Protection grade:IP23 |
||
Electric welding machine |
Droop characteristics (CC) |
||
Rated power |
kw |
12.4 |
|
Rated current (Single/Dual) |
A |
360/200 |
|
|
Rated voltage (Single/dual) |
V |
34.4/28 |
|
Unload voltage(Single/dual) |
V |
85 |
|
Rated usage rate % |
V |
50 |
|
Current adjustment range(Single/Dual) |
A |
6-400/40-200 |
|
Constant characteristics(CV) | |||
Unload voltage |
V |
85 |
|
Rated power |
kw |
9.6 |
|
Rated current |
A |
320 |
|
Voltage ajustment scope |
V |
15-35 |
|
Rated usage rate |
% |
80 |
|
Electric generator |
Rated power |
kw |
15 |
Rated voltage |
V(AC) |
400 |
|
Rated current |
A |
22.7 |
|
Phase number |
3-phase 4-wire |
||
Power factor |
% |
0.8 |
|
frequency |
Hz |
50 |
|
Incentive methods |
Brushlesss excitation |
||
Drive |
Direct coupling |
||
Emission stage |
Non road Phase III |
||
Form |
4-stroke 4-cylinder |
||
Air displacement |
L |
1.372 |
|
Rated output power |
kW |
22 |
|
Rated rotation |
rpm |
3000 |
|
Start mode |
Electric start 12V |
||
fuel |
light diesel oil |
||
Cooling mode |
water |
||
Other |
Fuel tank capacitance |
L |
75 |
Battery Capcitance |
12V-45An |
||
Dimension(L*W*H) |
mm |
1530*710*865 |
|
Net weigh |
kg |
550 |
|
noise |
dB |
75(7M) |
|
