Help CenterLIGHT VERTICAL MULTISTAGE CENTRIFUGAL PUMP MONDEL MODEL# CDLF12-90 5.5KW
Related Products
-
LIGHT VERTICAL MULTISTAGE CENTRIFUGAL PUMP MONDEL MODEL# CDLF8-50 2.2KWCNY 2600 - 3300MOQ: 1 Set -
LIGHT VERTICAL MULTISTAGE CENTRIFUGAL PUMP MONDEL MODEL# CDLF8-60 2.2KWCNY 2700 - 3400MOQ: 1 Set
-
LIGHT VERTICAL MULTISTAGE CENTRIFUGAL PUMP MONDEL MODEL# CDLF16-100 11KWCNY 5300 - 6200MOQ: 1 Set
-
LIGHT VERTICAL MULTISTAGE CENTRIFUGAL PUMP MONDEL NO. CDLF2-50 0.55KWNegotiableMOQ: 1 Set
-
LIGHT VERTICAL MULTISTAGE CENTRIFUGAL PUMP MONDELCNY 3600 - 5500MOQ: 1 Set
CDLF12-90 5.5KW Application
QDL/QDLF is a king of multifunctional products.it can be used to convey various medium from tap water to industrial liquid at different temperature and with different flow rate and pressure.QDL type is applicable to conveying- corrosive liquid, While QDLF is suiable for slightly corrosive liquid.
Water supply: water filter and transport in Waterworks,boosting of main pipeline,boosting in high-rise buildings.
Industrial boosting: Process flow water system,cleaning system. High-pressure washing system,fire fighting sysem.
Industria liquid conveying: Cooling and air-conditiong system, Boiler water supply and condensing system,machine-associated Purpose,acids and alkali
Water treatment: Ulrafitation system,reverse osmosis system, Distillation system,separator ,swimming pool
Irrigation: Farmiand irrigation,spray irrigation,dripping irrigation.
Operation conditions
Thin,clean,non-flammable and non-explosive liquid containing No solid granules and fibers.
Liquid temperature type:-15℃-+70℃ Hot water type: +70℃-+120℃ Amblent temperature: up to +40℃ Altitude: up to 1000m
Pump
QDL/QDLF is a kind of vertica non-self priming multistage
Centrifugal pump,which is driven by a standard electric motor. The motor output shaft directly connects with the pump
Shaft through a coupling. The pressure-resistant cylinder and Flow passage components are fixed between pump head and in-and outlet section with tie-bar bolts.The inlet and outlet are located at the pump bottom at the same plane. This kind of pump can be equipped with an intelligent
protector to effectively prevent it from dry-running,out-of-phase and overload.
Electric motor
Full-enclose air-blast two-pole standard motor Protection class: IP55 Insulation class: F
Standard voltage,50HZ:1X220-230/240V
3X200-220/346-380V3X220-240/380-415V3X380-415V
