Help CenterCast Iron T-slotted Base Plates/Floor Plates
Related Products
-
Cast Iron T-slotted Bed Plates/Floor PlatesUS$ 1000 - 10000MOQ: 1 Set -
Cast Iron T-slotted Clamping Plates/Floor PlatesUS$ 1000 - 10000MOQ: 1 Set
-
Cast Iron T-slotted Floor Tables/PlatesUS$ 1000 - 10000MOQ: 1 Set
-
Cast Iron T-slotted Surface Plates/ TablesUS$ 1000 - 10000MOQ: 1 Set
-
Cast Iron T-slotted Floor Tables/Plates for Machine ToolUS$ 1000 - 10000MOQ: 1 Set
T-slot combination to your specification, in cast iron. Nevertheless, standard floor plates are available in a large range of width and length combinations. Floor plates can be assembled to achieve larger plate areas.
STANDARD PLATE WIDTH (in mm):
1000, 1500, 2000, 2500 and 3000 (mm)
STANDARD PLATE LENGTH (in mm):
1500, 2000, 2500, 3000, 3500, 4000, 4500, 5000, 5500, 6000, 6500, 7000, 7500, 8000 (mm)
Popular sizes:
No. |
Length(mm) |
Width(mm) |
Height(mm) |
Surface accuracy (according to DIN876) |
2000 |
1500 |
|||
2500 |
1500 |
300 |
II/III |
|
3 |
3500 |
1500 |
300 |
II/III |
4 |
4000 |
1500 |
300 |
II/III |
5 |
4500 |
1500 |
300 |
II/III |
6 |
2500 |
2000 |
300 |
II/III |
7 |
3000 |
2000 |
300 |
II/III |
8 |
4000 |
2000 |
300 |
II/III |
9 |
4500 |
2000 |
300 |
II/III |
10 |
5000 |
2000 |
300 |
II/III |
11 |
5500 |
2000 |
300 |
II/III |
12 |
6000 |
2000 |
300 |
II/III |
13 |
6500 |
2000 |
300 |
II/III |
14 |
7000 |
2000 |
II/III |
|
15 |
8000 |
2000 |
300 |
II/III |
Other sizes and surface accuracy on request.
In case of non-standard sizes, clients are requested to provide information like:
- length, width and height of plate
- load bearing capacity required
- type of intended use
- whether floor mounting type or stand mounting type
- flatness accuracy of top working surface
- size, number and pitch of T-slots
- T-slot tolerances.
Large plates can be connected by single piece as following:
L(mm) |
W(mm) |
|||||
2000 |
2500 |
3000 |
3500 |
4000 |
||
3500 |
3500 |
2000 |
2500 or 1250+1250 |
3000 or 1500+1500 |
1500+2000 |
2000+2000 |
4500 |
4500 |
|||||
5500 |
5500 |
|||||
6500 |
6500 |
|||||
7500 |
7500 |
|||||
8500 |
4000+4500 |
|||||
9500 |
4000+5500 |
|||||
10500 |
4000+6500 |
|||||
11500 |
4000+7500 |
|||||
12500 |
4000+4000+4500 |
|||||
13500 |
4500+4500+4500 |
|||||
14500 |
4500+5000+5000 |
|||||
15500 |
5000+5000+5500 |
|||||
16500 |
5500+5500+5500 |
|||||
17500 |
5500+6000+6000 |
|||||
18500 |
6000+6000+6500 |
|||||
19500 |
6500+6500+6500 |
|||||
20500 |
6500+7000+7000 |
|||||
We are professional manufacturer in cast iron plates tables for many years, pls visit our web to know more :.
If any interests, pls contact Grace Chen,thank you!
