EN Standard Steel Rail 60 E1 Rail

FOB Price

Negotiable / Ton

10 Tons(Min. Order)

Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

EN STANDARD STEEL RAIL

What is EN Standard Steel Rail?

EN Standard Steel Rail is a common type of steel rails,which are produced according to EN 13674-1-2003 standard. Usually, EN Standard Steel Rail is mainly made by Material R260/R350HT. The Sizes of EN Standard Steel Rail include: 49 E1, 50 E2, 50 E4, 54 E1, etc. The main length of EN Standard Steel Rail is 12-25m.

Types of EN Standard Steel Rail

The common EN Standard Steel Rails includes about 12 sizes,such as 49 E1,49 E2,50 E1,50 E2,50 E4,50 E5,50 E6,54 E1,54 E2,54 E3,55 E1,60 E1 Railroad steel rail.

Specifications of EN Standard Steel Rail

EN standard steel rail
Size	Dimension(mm)				Weight	Material	Length
Size	Head(mm)	Height(mm)	Bottom(mm)	Web(mm)	Weight	Material	Length
49 E1	67	149	125	14	49.39	R260/R350HT	12-25m
49 E2	67	148	125	14	49.1	R260/R350HT	12-25m
50 E1	65	153	134	15.5	50.37	R260/R350HT	12-25m
50 E2	72	151	140	15	49.97	R260/R350HT	12-25m
50 E4	70	152	125	15	50.46	R260/R350HT	12-25m
50 E5	67	148	135	14	49.9	R260/R350HT	12-25m
50 E6	65	153	140	15.5	50.9	R260/R350HT	12-25m
54 E1	70	159	140	16	54.77	R260/R350HT	12-25m
54 E2	67.01	161	125	16	53.82	R260/R350HT	12-25m
54 E3	67	154	125	16	54.57	R260/R350HT	12-25m
55 E1	62	155	134	19	56.03	R260/R350HT	12-25m
60 E1	72	172	150	16.5	60.21	R260/R350HT	12-25m

Supplier of EN Standard Steel Rail

Signum Rail is a reliable steel rail material supplier in China. If you want to inquire more details about the EN Standard Steel Rail, please feel free to contact Signum Rail. We’ll feed back to you as soon as possible.

Service of EN Standard Steel Rail supplied by Signum

European Standards and CE Marking

5 years warranty.

Customization service according to your need.

More details about American standard steel rail, please feel free to contact Signum Rail.

Railroad Steel Rail and Railroad Rail Accessories Supplier, Signum Rail.
