Economical Large Power 3 Phase 380V AC Drive for Permanent Magnet Synchronous Motors (SPM & IPM)

Economical Large Power 3 Phase 380V AC Drive for Permanent Magnet Synchronous Motors (SPM & IPM) thumbnail-1
Economical Large Power 3 Phase 380V AC Drive for Permanent Magnet Synchronous Motors (SPM & IPM) photo-1
US$ 2263 - 2514 MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Hznon
Place of Origin:
China
Model Number:
HK300F-030G-T4
Contact Supplier Request Quote Chat Now
Shenzhen Hznon Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Hznon
Place of Origin China
Model Number HK300F-030G-T4
Type Other, AC/AC inverters
Size 255*439.6*209.6mm
Weight 17KG
Output Power Other, 30kW
Output Type Triple
Output Current 60A
Output Frequency 0-300Hz
Output Voltage 0-380V
Input Voltage 380V

WELCOME TO HZNON! ONE MORE CHOICE OF INDUSTRIAL AUTOMATION PRODUCTS!

With the world-leading sensorless current vector control technology (SVC) for synchronous motor, KE300F can accurately identify the motor parameters, dynamically estimate the rotor speed and pole position, and can easily drive all types of permanent magnet synchronous motors (SPM & IPM). KE300F can be widely used for the synchronous motor driving applications where better speed control and low-frequency torque are required.

S2   1AC    220V          0.4~5.5kW
T2    3AC   220V           1.5~90kW
T4    3AC   380V         1.5~800kW
T6    3AC   660V        15~1000kW

3AC 380V input/ 3AC 380V output
Model NO. Motor Rated Input Current (A) Rated Output Current (A)
kW HP
HK300F-5R5G-T4 5.5 7.5 15 13
HK300F-7R5G-T4 7.5 10 20 17
HK300F-011G-T4 11 15 26 25
HK300F-015G-T4 15 20 35 32
HK300F-018G-T4 18.5 25 38 37
HK300F-022G-T4 22 30 46 45
HK300F-030G-T4 30 45 62 60


Product Features:

1. Leading synchronous motor sensorless vector control (sVc)
With the world-leading sensorless vector control technology (SVC) for
synchronous motor, capable of easily driving all types of permanent magnetsynchronous motors (SPM & IPM) with no need encoder feedback.

2. Enhanced overexcitation regulation
With enhanced overexcitation regulation, providing fast stop with no need ofbraking resistor.

3. Non-stop when instantaneous power off
With the capability of non-stop when instantaneous power off, ensuring thesystem continuously operate without tripping in case of instantaneous poweroff.

4. Ultra-high speed flux-weakening control
With ultra-high speed flux-weakening control, the max. frequency could be up to500Hz(SVC), easy for the applications requiring high speed.

5. Excellent design and superb manufacturing process
With large design margin for key components and PCB;
Adopting industry-leading automatic spraying and strict automatic testing standards,making sure more stable and reliable products;
With optimized control algorithms and comprehensive protection functions, makingmore outstanding performance of the complete product.



MORE INFORMATION, PLS CONTACT US!
