Brand Name Hznon
Place of Origin China
Model Number MPS-H-3.5K-24110
Type DC/AC Inverters
Size 472*298*143mm
Weight 9.5kg
Output Power Other, 3500w
Output Type Single
Output Current 80A
Output Frequency 50Hz/60Hz
Output Voltage 230VAC
Input Voltage 120-500VDC

WELCOME TO HZNON! ONE MORE CHOICE OF SOLAR PRODUCTS!

HZNON has been committed to providing solar products for many years, and has obtained good feedback from customers, providing more and better choices for one-stop service customers.

Product Features:

1.Pure sine wave output
2.Output power factor 1.0

3.Programmable supply priority for PV, Battery or Grid
4.User-adjustable charge current and voltage

5.Wide PV input range (120Vdc-500Vdc),110A MPPT SCC
6.Working without batteries in sunny day

7.WIFI Monitoring Function (optional)
8.Anti-dusk kit for harsh environment(optional)

9.LCD remote control with 10 meters wire(optional)
10.PV and electricity complementary

11.Use with lithium batteries
12.Remove LCD Display
14.Parallel function for 6pcs


MODEL MPS-H-3.5K-24110 MPS-H-5.5K-48110
Rated Power 3500VA/3500W 5500VA/5500W
INPUT
Voltage 230VAC
Selectable Voltage Range 170-280VAC（for personal computers）
90-280VAC（for   home appliances）
Frequency Range 50Hz/60Hz（Auto sensing）
OUTPUT
AC Voltage Regulation（Batt . Mode） 230VAC±5%
Surge Power 7000VA 11000VA
Efficiency（Peak）PV to INV 97%
Efficiency（Peak）BAT to INV 94%
Transfer Time 10ms（for personal computers）
20ms（for   home appliances）
Wave form Pure   Sine Wave
BATTERY&AC   CHARGER
Battery Voltage 24VDC 48VDC
Floating Charge Voltage 27VDC 54VDC
Overcharge Protection 33VDC 63VDC
Maximum charge current 80A 80A
SOLAR   CHARGER
MAX.PV Array Power 5000W 6000W
MPPT Range@ Operating Voltage 120-450VDC
Maximum PV Array Open Circuit Voltage 500VDC
Maximum Charging Current 110A
Maximum Efficiency 98%
PHYSICAL
Dimension. D*W*H（mm） 472*298*143
Net Weight（kgs） 9.5kg 10.5kg
Communication Interface RS485/RS232（Standard）
WIFI（Optional）
OPERATING   ENVIRONMENT
Humidity 5% to   95% Relative Humidity（Non-condensing）
Operating Temperature 0℃ to   55℃
Storage Temperature -15℃   to 60℃


PLS CONTACT US FOR MORE INFORMATION!
