Zero buoyancy network cable Twisted-shielded 4 pairs of 8-core 23/24/26AWG sea water proof network cables

Zero buoyancy network cable Twisted-shielded 4 pairs of 8-core 23/24/26AWG sea water proof network cables

Zero buoyancy network cable structure:

Conductor: multi-strand ultrafine stranded oxygen-free copper wire

Insulation: special sea water resistant high density polyethylene

Color: Zero buoyancy cable 8-core standard color distinction

Shielding: tinned copper wire textile shielding

Density: more than 85%

Tensile parts: imported Kevlar bulletproof wire high density braid

Tensile strength: 100KG, can be customized

Jacket: Special seawater resistant polyurethane (PUR)

Color: Black, gray, orange

Rated voltage: Cross section test voltage: 2500V

Zero buoyancy cable operating temperature range:

Fixed installation -30℃ to +85℃

Mobile installation: -20℃ to +85℃

Zero buoyancy cable bending radius:

Fixed installation: 5 x cable diameter (D)

Mobile installation:

When the travel is less than 10 meters, the bending radius is 7.5×d

When the stroke is ≥10 meters, the bending radius is 10×D

Zero buoyancy cable application range:

Zero buoyancy cable is suitable for freshwater environment such as rivers, lakes and waves and saltwater environment such as saline wetlands and Marine environment, zero buoyancy cable has the characteristics of light weight, zero gravity in the water, and is applied to a variety of underwater intelligent equipment, such as underwater robots, underwater monitoring, underwater mapping, Marine environment detection and protection and Marine resources development and so on.

Zero buoyancy network cable features:

Anti-seawater corrosion, anti-oil, cold resistance, anti-corrosion, anti-UV, flame retardant, long bending life

Suitable for frequent mobile installation.

Zero buoyancy network cable Twisted-shielded 4 pairs of 8-core 23/24/26AWG sea water proof network cables
