4 Meter IR Oven for PCB Drying
- 1000 Set / Sets per Month
- Shenzhen
- T/T L/C
Product Details
Brand Name: | Tamprinter | After-sales Service Provided: | Overseas third-party support available | Condition: | New |
Product Description
4 meter IR oven For PCB drying
Parameters:
1. | Conveyor length :6000 (Inlet 1m+oven 3M+0.8m cool system+ Outlet 1.2m) |
2 | Conveyor width:650mm steel BELT, 1cylinder Lift open oven cover |
3 | machine size: (L)6100x(W)1250x(H)1360mm |
4 | working power: AC 380V 50HZ 3phase 4 line,infrared quartz Lamp heat to top 20pcs*1kw |
5 | Work Temperature 150 Celsius ,adjustment: RT-200 Centigrade ,1PCS VFD control temperature |
6 | constant temperature will be 5º C more or less ,2 PCS Circulation fan |
7 | temperature resolution: 1º C ,2 'Exit'= smoke exhaust |
8 | 1PCS motor control belt ,speed controller 0~5m/min adjustable |
9 | Gross weight: 350 KG |
Warranty | Spare infrared quartz Lamp 8 PCS For all our machines, we provide one-year warranty. Life-long on-line technical support and provide free parts when problems occur within one year not including shipping cost. Any warranty shipping cost to us is responsible by buyer. Any shipping cost to buyer is responsible by us. |
Description:
IR Drying tunnel for variety of screen printing, pad printing and spraying thermosetting ink processing such as heat press, electric products, ( silicon, electric membrane film key press, window glass. )
This conveyor dryer is widely used in the drying of screen printing industry,is especially suitable for solidifying heat-set and special type of printing ink.This tunnel dryerenables the production of printed products with good colorfastness, high flexibility and high gloss.
Features:
1. Intelligent temperature control system,easy operation,can control of temperature deviation effective.
2. adopt hot circulating system,save energy effectivly.
3. TeflonE screen belt , customers' designs are welcome
4.Far infrared heating pipe is especially suitable for solidifying heat-set and special type of printing ink.
5.Adjustable belt speed and tunnel temperature controls.
