Detailed Features
1. Sensor Beam adopt super power military transmitting tube,can guarantee transmitting distance and service life.
2. Active Infrared Sensor Beam adopt 4 channel frequency adjustment can avoid mutual interference when install crossed or face to face.
3. Digital tube display, the signal strength is more intuitive and convenient.
4. Adopt aspherical lens which required high manufacturing process, thereby increasing the degree of aggregation of infrared light emission, which make the infrared emission distance guaranteed.
5. Microprocessor control circuit, signal is more stable compared with competitor's logic circuit,strong anti false alarm ability.
6. The industry's most advanced digital filtering technology, with better accuracy and higher stability compared with traditional analog rate
7. Waterproof design,can be used indoor and outdoor
8. Beam interruption time adjustable according to environment,reduce false alarm;
9. "C" type relay is compatible with various alarm panel;
10. Built-in tamper switch,case remove alarm,can prevent criminals destroy detector;
11. Double Beam Active Infrared Sensor Beam Range Sensor:30/60/100/150M optional
Technical specifications:
■ Two beams detection mode: two infrared beams were cut off at the same time. (ABT-30, ABT-60,ABT- 80, ABT-100, ABT-150 selection)
■ Trip time: 50ms, 100ms, 250ms, 500ms (optional)
■ Beam frequency: 4 optional
■ Power supply voltage:DC 12V-18V
■ Current max: 90mA
■ Alarm cycle: 2S, 50ms (optional)
■ Protection level: IP65
■ Working temperature: - 25℃ -55℃
■ Ambient humidity: 95% Max
■ Correction angle: 180 degrees (90 degrees), vertical 90 degrees (10 degrees)
