Help CenterIRLML2402TRPBF Infineon Technologies MOSFET MOSFT 20V 1.2A 250mOhm 2.6nC LogLvl
Related Products
-
IXTQ60N20T IXYS MOSFET MSFT N-CH TRENCH GATE -GEN1US$ 1.3 - 4.5MOQ: 1 Piece -
STP5N105K5 STMicroelectronics MOSFET N-channel 1050 V, 2.9 Ohm Typ 3 A MDmesh K5 Power MOSFETs in TO-220 PackageUS$ 0.5 - 2.5MOQ: 1 Piece
-
STP21N90K5 STMicroelectronics MOSFET N-Ch 900V 0.25 Ohm 18.5A MDmesh K5US$ 2 - 6.5MOQ: 1 Piece
-
Power MOSFET DMP3125L-7 Factory Direct Supply IC Components MOSFETUS$ 0.059 - 0.48MOQ: 10 Pieces
-
2N7002P,215 Nexperia MOSFET 2N7002P/SOT23/TO-236ABUS$ 0.01 - 0.14MOQ: 10 Pieces
Manufacturer: Infineon
Product Category: MOSFET
RoHS: Details
Technology: Si
Mounting Style: SMD/SMT
Package / Case: SOT-23-3
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 20 V
Id - Continuous Drain Current: 1.2 A
Rds On - Drain-Source Resistance: 250 mOhms
Vgs - Gate-Source Voltage: - 12 V, + 12 V
Vgs th - Gate-Source Threshold Voltage: 700 mV
Qg - Gate Charge: 2.6 nC
Minimum Operating Temperature: - 55 C
Maximum Operating Temperature: + 150 C
Pd - Power Dissipation: 540 mW
Channel Mode: Enhancement
Packaging: Reel
Packaging: Cut Tape
Packaging: KXXReel
Brand: Infineon Technologies
Configuration: Single
Fall Time: 4.8 ns
Forward Transconductance - Min: 1.3 S
Height: 1.1 mm
Length: 2.9 mm
Product: MOSFET Small Signals
Product Type: MOSFET
Rise Time: 9.5 ns
factory pack quantiy: 3000
Subcategory: MOSFETs
Transistor Type: 1 N-Channel
Typical Turn-Off Delay Time: 9.7 ns
Typical Turn-On Delay Time: 2.5 ns
Width: 1.3 mm
Unit Weight: 0.000282 oz
