Hydrogen Power Plants | WellCare Energy Global | Hydrogen Generation Plant
US$ 130000 - 500000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
WellCare
Place of Origin:
China
Model Number:
HKHG-00
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
90 days
Related Products
-
Hydrogen Power Generation Plant, Hydrogen Production Plant DesignUS$ 8000 - 50000MOQ: 1 Set -
Hydrogen Manufacturing Plant, Green Hydrogen Power Plant, Hydrogen Generating SystemUS$ 130000 - 500000MOQ: 1 Set
-
Hydrogen Gas Plants Onsite Hydrogen Generator Electrolyzer Hydrogen Gas GeneratorsUS$ 130000 - 500000MOQ: 1 Set
-
Hydrogen Electrolyzer Generator, Hydrogen Generating Plant, Hydrogen Gas Onsite GeneratorUS$ 8000 - 50000MOQ: 1 Set
-
High Purity Liquid Oxygen From LOX Plants, Oxygen Gas for Cylinders FillingUS$ 10000 - 500000MOQ: 1 Set
Brand Name
WellCare
Place of Origin
China
Model Number
HKHG-00
Certification
CE & ISO 9001
After-sales Service Provided
Engineers available to service machinery overseas
Warranty
1 year
Weight
700 kg
Dimension(L*W*H)
2.5 * 3.2 * 2.8 meters
Condition
New
Voltage
380 V
Usage
Hydrogen
Power(W)
4.8 kWh/Nm3
Production Rate
45Nm3/hr
Products Description
1.Main Process Equipment:
One set of electrolyzer cell stack with H2 output at 45 Nm3/hr, and operating pressure at 1.0-1.5MPa.
Lye & gas treatment system, including separator towers for H2-lye separating, washing and cooling. 1 set
Lye & gas treatment system, including separator towers for H2-lye separating, washing and cooling. 1 set
Lye solution pump, cooler, filter and other auxiliary instruments 1 set
Deaerator with catalyst, dryer, H2 gas coolers, instruments, valves and other auxiliaries installed in skid. 1 set
lye supplementary unit, including DM water tank, Lye tank (SS 304), feed water pump and so on in skid. 1 set
lye supplementary unit, including DM water tank, Lye tank (SS 304), feed water pump and so on in skid. 1 set
1.1 Electrical control system:
Power supply unit which high converting efficiency from AC to DC power through latest technology without HV or MV input
AC power 1 set
1.2 Instrument control system:
Local control panel with CPU and power modules installed based on one PLC system (Siemens S7 series) to monitor and
control the operation H2 generating package. 1 set
control the operation H2 generating package. 1 set
1.3 Miscellaneous:
Pipeline, fittings, valves, cables and accessories for factory installation and field construction of both hydrogen generating
package.
Pipeline, fittings, valves, cables and accessories for factory installation and field construction of both hydrogen generating
package.
2. Equipment detailed description and features:
The integrated and compact hydrogen generating system by water electrolysis, which has been developed and manufactured by “GH” with capacity 45Nm3/h of H2 product. The system is very compact with good performance and high operational reliability. The followings describe the main components and their function in the hydrogen generating system by water electrolysis.
2.1 Generating of hydrogen:
The hydrogen gas will be generated through H2 generation, in which there are the following components with corresponding functions.
2.2 Automatic control system for hydrogen generation system by water electrolysis:
A monitoring system in hydrogen plant consists of HMI, control cabinet and primary instruments, etc.
A monitoring system in hydrogen plant consists of HMI, control cabinet and primary instruments, etc.
2.3 H2 gas leakage detection system:
The H2 gas leakage should be detected all the time automatically for the hydrogen generating system. Supposing there is any H2 gas leakage happened, the detector will immediately send a signal to control program to trip the hydrogen generating system the operator could use portable hydrogen leakage detector to monitor the hydrogen leakage or not. These measures can be assured to protect the hydrogen generating room from hydrogen accumulated for safety and reliability.
