Features:
electrical and electronic systems.If you need more models about our test equipment, please reference our chamber-testing（.）com
Applicable Industries: Salt Spray Test Machine Cyclic Corrosion Testers Salt Fog Cabinets Chamber is used to test the anti-erosion quality of the surface of all materials after the rust-proof of painting, coating, electroplating, anoding and rust-proof of greasing.anti corrosion treatment for a variety of materials, corrosion resistance of their products.
Salt Spray Cycling Test Chamber can be used to simulated condition that more often meet at natural environment, and then deteriorated the natural environment to be tested, such as the salt spray, dry, wet, room temperature, low temperature environment, it is used to test the anti-erosion quality of the surface of all materials after the rust-proof of painting, coating, electroplating, anoding and rust-proof of greasing.anti corrosion treatment for a variety of materials, corrosion resistance of their products.
Specifications :
| Volume(L) | 108 | 270 | 480 | customi-zable | ||
| Internal Size W×H×W(mm) |
600×400×450 | 900×500×600 | 1200×500×800 | |||
| External Size W×H×W(mm) |
1150×1090×672 | 1450×1200×842 | 2080×1285×1240 | |||
| Performance Index | Temperature Range | LaboratoryTemperature Range :RT~50℃ Saturated air barrel Temperature Range :RT~63℃ |
||||
| Temperature Deviation | ±1.0℃ | |||||
| Temperature Uniformity | ≤2.0℃ | |||||
| Temperature Fluctuation | ±0.5℃ | |||||
| Heating Rate | Test Room RT→+50℃≤60 min Pressure Barrel RT→+63℃≤60 min |
|||||
| Salt fog deposition | 1~2ml/80 square meter (At least 16 hours were collected and averaged) | |||||
| Spray Pressure | 70~170Kpa | |||||
| Spraying Mode | Continuous spray | |||||
| Test time | 1~999(S,M,H)adjustable | |||||
| PH | 6.5~7.2 3.0~3.2 | |||||
| Main Part | Control System | temperature controller | ||||
| PT100 thermocouple (armor), PID control | ||||||
| Spraying System | The Nozzle is made of special glass material, the size and angle of spray can be controlled | |||||
| operate manual spray or set automatic spray according to program | ||||||
| Structural Features | Material Enclosure | Imported PVC polyethylene board is adopted | ||||
| Medicament refill cylinder | hidden type supplementary water gauge | |||||
| Pressurized air drum | SUS304# stainless steel high-pressure barrel | |||||
| Test Rack | The plane indexing frame can be used to adjust the Angle of fog falling or being foggy at any direction | |||||
| Cover Material | imported European acrylic board | |||||
| Spray Tower | air atomizing nozzle, height can be adjusted | |||||
| Spray volume collector | Cone funnel with diameter of 100mm | |||||
| Heating System | Titanium alloy heat pipe, steam heating, P.I.D. control heating | |||||
| Brine Tank | Made of PVC board | |||||
| Saturated air barrel | SUS304 Stainless | |||||
| Drain line | acid and alkali resistant PVC piping | |||||
| Heater | Titanium alloy armored electric heating tube (test chamber bottom heating) SUS316# stainless steel armoured heating tube (saturation barrel) |
|||||
| Standard Fittings | 1 set of nozzles, 2 fog collecting and measuring cylinders, 2 fog collecting collectors, etc. | |||||
| Safty Device | Leakage, short circuit, motor overheating, overload, over current protection | |||||
| Supply Voltage | AC220V 50Hz | |||||
| Environment Requirement | Temperature 5.0~+30.0℃,Humidity≤85%RH,Air Pressure 86Kpa~106Kpa | |||||
We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them,no matter where they come from. Each batch of parts is done quality sampling inspection before into the warehouse, and Each product before delivery is tested by the national authoritative third-party inspection agency
Advantage:
1 Programmable control, touch screen operation
2. It can spray regularly, intermittently and evenly
3.24 hours online
4.Sample chamber of each model
5. Best price, fast delivery
6.OEM,ODM
7.Oversea offices
8.Own import and export business license
9.ISO,CE,UL,ASTM,DIN,EN,GB,BS,JIS,ANSI,TAPPI,AATCC,IEC,VDE
