1200*1200mm automatic flaskless green sand moulding machine

FOB Price

USD $2000 - $50000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port Qingdao port or as customer's requirement
Payment Terms:T/T L/C D/P D/A Credit Card Cash Other
Delivery Detail:25 days

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:	bestech	Place of Origin:	China	Model Number:	XGA-02
Certification:	CE ISO	After-sales Service Provided:	Overseas service center available	Warranty:	1 year
Weight:	2560	Dimension(LWH):	125015501750	Condition:	New
Voltage:	customized	Power(W):	-

Product Description

Green Sand Automatic Flaskless Moulding Line

Full Automatic Horizontal Flaskless Molding Line is mainly suitable for moulding production of valves, mechanical parts, automobile parts, hydraulic parts, pipe fittings and fastening these parts, also suitable for ductile iron,gray iron, malleable cast iron and non-ferrous metails these materials,with advantages of high production efficiency, low investment, quick effect, energy-saving and environmental protection. This moulding line mainly consists of moulding machine, pouring line, cooling line, castings conveying system, and electric control, hydraulic control and pneunatic control system, which can realize full automatic control of sand feeding, moulding, pouring, cooling and castings movement.

Main characteristics as follows:

1. Horizontal parting, suspended shot sand, horizontal casting.
Pneumatically feeds moulding sand in vertical direction, has the best filling performance and completely improve the shadow defect caused by horizontal shooting sand. Simple process,convenient moulds and pouring gate, high product rate and strong applicability.

2. Adjustable castings height and compaction pressure
The user can choose the casting height and compaction pressure under different castings flexibly to ensure the reasonable use of moulding sand.

3. Convenient template replacement.
Template installation: fixedy by four screws, the replacement is completed within five minutes, and the mold is changed frequently.

4. Failure display
The fault is displayed on the touch screen, and the fault reason is displayed on the touch screen. The user can easily find the fault and take measures.

5. High reliability of hydraulic, pneumatic and electrical system.
The hydraulic, pneumatic and electrical components all adopt imported components to ensure the stable and reliable operation of the equipment and the service life.

6. Easier, more convenient and safer for core setting
All types of equipment manufactured by the company adopt a stable and reliable safety defense system.

7. Adopt servo hydraulic system to save energy.
With servo hydraulic system, the supply pressure of the system can be adjusted automatically according to the various stages of the equipment operation, reducing the loss of energy.

technical parameter:

Parameter	XGA-01	XGA-02	XGA-03
Sand Mould Size (LxWxH)	500x400x(120~150)	610x508x(130~180)	700*600(120-150)
Mould Way	Injection and Compaction	Injection and Compaction	Injection and Compaction
Compaction specific pressure	~1.0Mpa	~1.0Mpa	~1.0 Mpa
Power Mode	Hydraulic pressure	Hydraulic pressure	Hydraulic pressure
Max productivity	40s/mould(Excluding core setting time)	40s/mould(Excluding core setting time)	40s/mould(Excluding core setting time)

Contact Us

Qingdao Bestech Machinery Co.,Ltd: Contact namecassie han; Addresshuangdao district Qingdao,Shandong
