1000*1000mm Automatic Flaskless Sand Moulding Machine up Lower Shooting Sand
- Qingdao port or as customer's requirement
- T/T L/C D/P D/A Credit Card Cash Other
- 25 days
You May Like
-
800*700mm Horizontal Automatic Sand Molding Machine for Aluminum Castings
-
1200*1200 mm Automatic Flaskless Green Sand Moulding Machine
-
Manufacturer Automatic Horizontal Sand Moulding Machine With Sand Mold Rotary Line
-
Spinner Hanger Hook Shot Blasting Machine
-
Tumble Belt Shot Blasting Machine
-
Foundry Green Sand Molding Machine
Product Details
| Brand Name | bestech | Place of Origin | China | |
| Model Number | XGA-02 | Certification | CE ISO | |
| After-sales Service Provided | Overseas service center available | Warranty | 1 year | |
| Weight | 2560 | Dimension(L*W*H) | 1250*1550*1750 | |
| Condition | New | Voltage | customized | |
| Power(W) | - |
Product Description
Green Sand Automatic Flaskless Moulding Line
Pneumatically feeds moulding sand in vertical direction, has the best filling performance and completely improve the shadow defect caused by horizontal shooting sand. Simple process,convenient moulds and pouring gate, high product rate and strong applicability.
The user can choose the casting height and compaction pressure under different castings flexibly to ensure the reasonable use of moulding sand.
Template installation: fixedy by four screws, the replacement is completed within five minutes, and the mold is changed frequently.
The fault is displayed on the touch screen, and the fault reason is displayed on the touch screen. The user can easily find the fault and take measures.
The hydraulic, pneumatic and electrical components all adopt imported components to ensure the stable and reliable operation of the equipment and the service life.
All types of equipment manufactured by the company adopt a stable and reliable safety defense system.
With servo hydraulic system, the supply pressure of the system can be adjusted automatically according to the various stages of the equipment operation, reducing the loss of energy.
technical parameter:
Parameter | XGA-01 | XGA-02 | XGA-03 |
Sand Mould Size (LxWxH) | 500x400x(120~150)
| 610x508x(130~180) | 700*600(120-150) |
Mould Way | Injection and Compaction | Injection and Compaction | Injection and Compaction |
Compaction specific pressure | ~1.0Mpa | ~1.0Mpa | ~1.0 Mpa |
Power Mode | Hydraulic pressure | Hydraulic pressure | Hydraulic pressure |
Max productivity | 40s/mould(Excluding core setting time) | 40s/mould(Excluding core setting time) | 40s/mould(Excluding core setting time) |
Our Service:
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available. UEM&UBM are welcomed.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Special discount and protection of sales are provided to our distributor.
6. Professional factory : We are manufacturer, specializing in producing all kinds of machinery for more than 20 years, competitive with good quantity.
7.Sample: We can send out sample for test in one week if the order quantity is big enough. But the shipment charges is usually paid by your side, the charges will be rebounded when we have formal order.
8.As an honest seller, we always use superior raw material, advanced machines, skilled technicians to ensure our products to be finished in high quality and stable feature. Welcome to contact us or visit our company.
Q:How many days will be used to produce this sand molding machine?
A:Normally within 15 workdays or according to your requirement
Q:Can you provide installation and commissioning overseas?
A:We can supply oversea service if needed
Q:Are you manufacture or trading company?
A:We are manufacture,welcome to visit our factory
