Home > Consumer Electronics > Two Way Radio > Handheld Two Way Radio > Original Kenwood TK-3207GD Transceiver Compact UHF 400-470MHz DMR HF Walkie Talkie Waterproof Two-way Radio
Original Kenwood TK-3207GD Transceiver Compact UHF 400-470MHz DMR HF Walkie Talkie Waterproof Two-way Radio
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
YAESU HX380 Two Way Radio Walkie Talkie Submersible 5 Watt Handheld Commercial VHF With LMR ChannelsNegotiableMOQ: 1 Piece -
IC-M37 6W 5KM VHF Transceiver Marine Boat Walkie Talkie Two Way RadioNegotiableMOQ: 1 Piece
-
IC-M36 6W 10KM VHF Marine Transceiver IPX7 Walkie Talkie TransceiverNegotiableMOQ: 1 Piece
-
ICOM IC-M23 Handheld Walkie Talkie Long Range For Emergency Waterproof for ICOMNegotiableMOQ: 1 Piece
-
5W Vhf Icom IC-M33 Portable Communication Radio IPX7 Waterproof Long Range Marine Walkie TalkieNegotiableMOQ: 1 Piece
Model Number
TK-3207GD
Original Kenwood TK-3207GD transceiver compact UHF 400-470MHz DMR HF walkie talkie waterproof two-way radio
Products display
Product Description
| GENERAL SPECIFICATIONS | |
|
Band
|
400-470MHz |
| Power Output | ≤5W |
| Channel Spacing |
Analog: 12.5/25KHz Digital: 12.5KHz |
| Channel Capacity | 32 |
| Dimensions(HXWXD) | 122 X 54 X33 mm |
| Weight(Radio + KNB-45L) | 280g |
| Oprerating temperature | -30℃ - 60℃ |
| Power Supply(Nominal) | 7.4V |
| TRANSMITTER SPECIFICATIONS | |
| Digital Modulation | 7K60FXD, 7K60FXE |
| Modulation limit | 2.5KHz |
| Modulation noise | -40dB |
| Spurious emission |
-36dB≤1GHz -30dB>1GHz |
| Adjacent channel power | -60dB |
| Modulation characteristics | +1dB, -3dB |
| RECEIVER SPECIFICATIONS | |
| Digital Sensitivity | 0.2 uV |
| Frequency stability | ±2.5ppm |
| Intermodulation | 55 dB |
| Adjacent Channel Selectivity | 60 dB |
| Spurious Rejection | 12 dB |
| AUDIO SPECIFICATIONS | |
| Rated Audio | 1 W |
| Audio Distortion at Rated Audio | 5% |
| Conducted Spurious Emissions | -57 dBm |
