Home > Manufacturing & Processing Machinery > Spraying Machinery & Spreading Equipment > Coating Machinery > PCB Solder Resist White Ink UV Curing Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Tamprinter
Place of Origin:
China
Model Number:
TM-UV-PCB
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
7 days
Related Products
-
TM-UV8m High Quality Ice Flower Effect UV DryerUS$ 8,800 - 8,900MOQ: 1 Set -
TM-UV1000L Ce Certificate UV Curing MachineUS$ 2,950 - 2,990MOQ: 1 Set
-
TM-UV-100-2 MDF Plate Portable UV Curing MachineUS$ 400 - 500MOQ: 1 Set
-
TM-LED600-6 MDF Plate Mini LED UV DryerUS$ 3,550 - 3,600MOQ: 1 Set
-
TM-UV750 Ce Approved UV Curing Machine for PaperUS$ 2,500 - 2,600MOQ: 1 Set
Brand Name
Tamprinter
Place of Origin
China
Model Number
TM-UV-PCB
Mecrcury lamps uv tunnel machine parameter:
shine width 600mm
power 9.6kw*3pcs lamp
machine with 3 Mecrcury lamps 160W/cm total 480W/cm
lamp to pcb 8~12cm
3000 mJ/cm2 at 3m/min
machine length 2.5~5m
price $6000~$7000
led uv tunnel machine parameter:
shine width 600mm
led power 1.2kw
led to pcb 1~3cm
water cooled system
totle power 1.5kw
3000 mJ/cm2 at 3m/min
machine length 1.5~5m
price $8000~$10000
hot tags: uv machine
