NI PXIE-6547 Industrial Control Card Module

Product Introduction

NI PXIe-6547 is a high-performance industrial control card module, with the following main product features:

High speed digital signal processing capability: This module has high-speed and accurate digital signal processing capabilities, which can achieve high-speed data acquisition and output. It supports up to 32 independent channels of digital input/output and can operate at a sampling rate of up to 100 MHz.

Flexible configuration and scalability: PXIe-6547 adopts PXI Express (PXIE) standard interface, which can be flexibly combined with other PXI/PXIE modules to achieve complex testing and control systems. This module also supports multi card synchronization, which can be triggered by software and hardware to achieve synchronization operations between multiple modules.

Rich input/output functions: PXIE-6547 provides various input/output functions, including digital input, digital output, timer/counter, and trigger circuit. It supports different signal levels such as TTL, LVDS, CMOS, and provides rich input/output connection options to facilitate connection with external devices.

High precision clock and trigger: This module is equipped with a high-precision internal clock source, which can be used to synchronize the operation of multiple modules. In addition, it also supports the input and output of external trigger signals, which can achieve precise trigger control and ensure the stability and reliability of the system.

Powerful software support: The NI-DAQmx driver software accompanying PXIE-6547 provides rich functions and easy-to-use programming interfaces, allowing for quick configuration, control, and data processing. In addition, this module also supports commonly used programming languages such as LabVIEW, C/C++, and Python, making it easy to develop various applications.

Product image display
