Product Introduction
NI PXI-5922 is a high-performance oscilloscope module launched by National Instruments (NI) for data acquisition and signal analysis applications on the PXI platform. This module has the following main features:
High speed sampling rate: The PXI-5922 module has a high sampling rate, which can achieve fast and accurate signal acquisition. It supports a sampling rate of up to 50 MS/s (megasamples/second) and can capture and analyze rapidly changing signals.
Broadband input: This module provides a broadband input channel and supports a wide range of signal frequencies. It is suitable for signal measurement and analysis from low frequency to high frequency, and can meet the needs of spectrum analysis and time-domain analysis in different applications.
The high-resolution ADC: PXI-5922 module uses a high-resolution analog-to-digital converter (ADC) to achieve accurate signal measurement. It has high ADC resolution, providing more detailed and accurate signal sampling results.
Multi channel input: This module supports multi channel input, with each channel having independent measurement capabilities. It can simultaneously collect multiple signal channels, suitable for applications that require parallel measurement of multiple signals.
Flexible triggering and synchronization functions: The PXI-5922 module has flexible triggering and synchronization functions, and can be configured with trigger sources, trigger types, and trigger conditions as needed. It supports multiple triggering modes, including edge triggering, level triggering, and software triggering, to achieve precise data collection and triggering control.
Powerful software support: This module is equipped with NI-DAQmx driver software, providing users with rich functions and easy-to-use programming interfaces. Users can use programming languages such as LabVIEW, C/C++, Python, etc. for programming and control, making it convenient and fast for data collection and signal analysis.
Product image display
