NI PXI-5422 Acquisition Card Module

Product Introduction

NI PXI-5422 is a high-performance acquisition card module from National Instruments (NI), used for the PXI (PCI eXtensions for Instrumentation) bus architecture. This module provides rich functions and flexible configuration options, suitable for various data acquisition and signal generation applications. Here are some product details for this module:

Acquisition function: PXI-5422 supports high-speed data acquisition with high resolution and High dynamic range. It can collect analog signals in real-time, including voltage, current, temperature, etc., and provide high-speed sampling rate and multi-channel acquisition capability.

Signal generation function: This module can generate various types of analog and digital signals. It supports multi-channel signal generation and has high-precision and high stability signal output capabilities. Users can generate various waveforms, pulses, frequencies, and other signals.

High speed sampling rate: The PXI-5422 module has a high sampling rate, which can achieve fast data acquisition and signal generation. It supports high-speed sampling and output, suitable for applications with rapid signal changes, such as spectrum analysis, vibration analysis, etc.

High resolution and precision: This module provides high-resolution and high-precision data acquisition and signal generation. It has low noise and low distortion characteristics, which can maintain the accuracy and quality of the signal.

Flexible input and output configuration: The PXI-5422 module has flexible channel configuration options that can be customized according to user needs. It supports different types of inputs and outputs, including voltage, current, differential signals, etc.

Multi channel support: This module supports multi-channel data acquisition and signal generation. Users can simultaneously collect or generate multiple signals and perform synchronization operations.

High speed data transmission and processing: The PXI-5422 module supports fast data transmission and processing, and can seamlessly integrate with other PXI modules and devices to build complex testing and measurement systems.

Product image display
