NI PXI-6255 Analog Input Acquisition Card

Product Introduction

NI PXI-6255 is a high-performance analog input acquisition card with the following product details:

Sampling rate and resolution: NI PXI-6255 supports high sampling rate and high-resolution analog inputs. Its sampling rate can reach 1.25 MS/s (single channel) or 12.5 MS/s (single channel, using multi-channel mode). The resolution is 16 bits, providing high-precision analog signal acquisition.

Number of channels and input range: This acquisition card provides 32 single ended or 16 differential input channels, which can adapt to different application needs. Each channel has independent configuration capabilities. It supports multiple input range options to adapt to analog signals of different amplitudes.

Input coupling and gain: The NI PXI-6255 supports multiple input coupling and gain options to meet different signal types and application requirements. Users can choose appropriate coupling methods and gain settings based on specific circumstances.

Trigger and synchronization function: The acquisition card has flexible trigger and synchronization functions, which can control data collection through software trigger, digital input trigger, or external trigger signals. At the same time, it also supports synchronization operations with other devices.

Hardware Timer and Counter: NI PXI-6255 has hardware timer and counter functions, which can be used for real-time measurement, frequency counting, pulse generation, and other applications. These functions enhance the flexibility and functionality of the acquisition card.

Software support and programming interfaces: The acquisition card is equipped with rich software support and programming interfaces, including LabVIEW, C/C++, Python, and more. This allows users to easily configure, control, and analyze data.

Product image display
