NI PXI-6514PXI Digital I/O Module

Product Introduction

NI PXI-6514 is a PXI digital I/O module launched by National Instruments. The following is a general product introduction for this module:

Multi channel digital I/O: The NI PXI-6514 module provides multiple digital input and output channels, which can simultaneously collect and generate multiple digital signals. Each channel has independent input and output functions, which can achieve digital signal processing with a high number of channels.

High speed data acquisition and output: This module has high-speed data acquisition and output capabilities, suitable for applications that require fast response and processing of digital signals. It supports high-speed digital signal sampling and generation, which can meet application scenarios with high real-time requirements.

Programmable level and voltage range: The NI PXI-6514 module supports programmable digital signal levels and voltage ranges. Users can choose appropriate levels and voltage ranges based on application requirements to adapt to different signal strength and level requirements.

Flexible triggering and synchronization functions: This module has flexible triggering and synchronization functions, which can achieve precise data collection and output control. It supports multiple triggering modes and external clock inputs, and can synchronize with other devices.

High precision and stability: The NI PXI-6514 module has high-precision and stable digital signal processing capabilities. It uses high-quality analog-to-digital converters (ADC) and analog-to-digital converters (DAC) to achieve accurate digital signal acquisition and generation.

PXI standard compatibility: This module complies with the PXI (PCI eXtensions for Instrumentation) standard and can seamlessly integrate with other PXI devices and systems. It can form a complete testing and measurement system with other PXI modules, achieving efficient digital signal processing.

Product image display
