Help CenterQuartz Single Tube Lamp 235V 1000W Replace 13168Z/98 Infrared IR Lamp
Related Products
-
14196Z/83 Replacement IR Lamp 400V 2500W Infrared LampUS$ 1 - 50MOQ: 2 Pieces -
220V 900W Quartz Infrared Single Tube LampUS$ 1 - 50MOQ: 2 Pieces
-
Replacement Dr.Fischer 13565X 235V 3000W Quartz Infrared LampUS$ 1 - 50MOQ: 2 Pieces
-
Bottle Blowing Infrared Heater Lamp Industrial Thermoforming Quartz Tubular IR Heater LampUS$ 1 - 50MOQ: 2 Pieces
-
Food Drying Medium Wave Infrared Lamp Carbon IR Quartz Heat Lamp For Water DryingUS$ 1 - 50MOQ: 2 Pieces
E-DEN Halogen Infrared Heater Lamps / Advantages
1: Can switch on and off frequently
2: 1~2 seconds fast response time to full power heating
3: Output power can be adjusted simply by voltage regulator (0V~lamp rated voltage)
4: Accurate(±1 ℃)heating temperature control with SCR regulator
5: Small installation space, flexible horizontal or vertical burning position
6: For all industrial applications, the highest working temperature up to 1000 ℃
7:Special Gold reflector (90% reflective rate) and Nano-ceramic reflector (70% reflective rate) coated on lamp quartz surface to reflect and increase the infrared radiation on heated objects
8: Different objects different matched IR radiation wavelength Short wave (1.0~1.4μm), Fast response medium wave (1.4~2.0μm), Carbon medium wave (2.0~2.5μm), Medium wave (2.2~3.2μm).
9: Higher density power output The highest surface power output of short wave lamp is 200KW/M2, Fast response medium wave lamp is 130KW/M2, Carbon medium wave lamp is 100KW/M2, Medium wave lamp is 60KW/M2.
10: We guarantee 5000 hours average working life.
E-DEN Short wave infrared lamp is designed with high heating power, the range of radiation wave is 1.0-1.4μm, it is particularly suited for fast response heating processes. This short wave infrared radiation penetrates more deeply into materials, as they can obtain their full-efficiency within seconds. In addition, a white or gold reflector can be fixed directly on the short wave infrared lamp to improve the energy radiation on the heating materials.
Ceramic Reflector Infrared Heat IR Lamp
Replacement: 13168Z/98
Voltage: 235V
Power: 2000W
End Cap: SK15
Tube diameter: 10mm～12mm
Total length: 357±1mm
* Our halogen infrared heat IR lamps are replacement designed for original 13168Z/98 IR heat lamp, and the heating lamp matches
the original specification.
