1000FT Cat5e UTP PVC Jacket 0.50mm 24AWG Ethernet Cable

1000FT Cat5e UTP PVC Jacket 0.50mm 24AWG Ethernet Cable photo-1
1000FT Cat5e UTP PVC Jacket 0.50mm 24AWG Ethernet Cable photo-2
1000FT Cat5e UTP PVC Jacket 0.50mm 24AWG Ethernet Cable photo-3
1000FT Cat5e UTP PVC Jacket 0.50mm 24AWG Ethernet Cable photo-4
1000FT Cat5e UTP PVC Jacket 0.50mm 24AWG Ethernet Cable photo-5
US$ 20 - 30 MOQ: 50 Cartons
Key Specifications
Get Latest Price
Brand Name:
OEM
Place of Origin:
China
Type:
Cat 5e
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo
Delivery Detail:
10 days
Brand Name OEM
Place of Origin China
Type Cat 5e
Number of Conductors 8

U/UTP CAT 5E Twisted Pair Installation Cable

LAN CABLE

Construction

Conductor:

24 AWG Solid Bare Copper

Pairs:

4 Pairs

Insulation:

0.91 mm HDPE

Insulation Colors:

Blue-White/Blue,Orange-White/Orange

Green-White/Green,Brown-White/Brown

Rip Cord:

Cotton

Out Jacket:

5.1±0.2 mm  PE

Electrical Characteristics

Impedance

1 - 100MHz 100±15 Ohms

Insulation Resistance

>5000MΩ*KM

Dielectric strength

DC  2500V  2S

Max.Conductor DC
Resistance 20ºC

9.5 Ohms/100m

Res. unbalance (%)

Max. 2.5

Pair to Ground
Capacitance Unbalance

330 pF/100m

Transfer Impendance

Max 10 mOhms/m  @100Mhz

Installation temp.

 -30 - 50ºC

Operation temp.

 -20 - 75ºC

 Application

•  Meets or exceeds requirements of ANSI/TIA-568-C.2 Category 5e and
   ISO 11801 2nd Edition Class D channel standards.

•  Meets or exceeds requirements of ANSI/TIA-568-C.2 and IEC 61156-5
   Category 5e component standards.

•  Third party tested to Category 5e channel compliance.

•  Meets requirements of IEEE 802.3af and IEEE 802.3at for PoE applications.

•  Descending length cable markings enable easy identification of remaining cable
   which reduces installation time and cable scrap.

•  Color Availability: Additional cable colors available.


Product Tags: cat5e , lan cable , network cable , utp cable , cat5
