Carbon Steel Automatic Evacuation Anti-Freeze Composite Eyewash

The surface of the pedal and box is coated with ABS anti-corrosion coating, and the main body of the eyewash is made of SS304 stainless steel, which is effectively resistant to various chemicals such as acid, alkali, salt and oil.

Easy to use and easy to operate. When in use, depress the pedal to automatically discharge water. Leaving the pedal, the water inlet control switch is automatically turned off. At this time, the unit automatically switches to the emptying state, automatically emptying the water in the pipeline to achieve the effect of antifreeze.

An optional flow regulator can be used to adjust the water flow according to the pressure of the water source. This effectively prevents secondary injuries to the injured person due to high water pressure.

Technical Parameters

1.Manufacturing Standards：ANSI Z358.1-2014

2.Main material：SS304(Optional Q235 or SS316L)

3.Function：Eyewash and shower

4.Working temperature：-10℃～55℃

5.Applicable medium: Drinking water or clear water at room temperature and in line with sanitary standards

6.Nominal pressure：1.0MPa

7.Work pressure：0.2MPa～0.4MPa

8.Inlet size：Internal thread 1" (can be customized according to user requirements)

9.Drain size：Internal thread 1" (can be customized according to user requirements)

10.Shower flow：≥75.7L/min

11.Eyewash flow：≥11.4L/min,(The eyewash nozzle is equipped with a buffer device to prevent secondary damage to the injured eye due to excessive water flow)

12. Shower head: The standard configuration is ABS shower head (optional stainless steel shower head)

13. Eye wash nozzle: The standard configuration is ABS eye wash nozzle (optional stainless steel eye wash nozzle)
