Stainless Steel Wedge Wire Slot Tube
US$ 50 - 200
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
GuangXing
Place of Origin:
China
Model Number:
GX
Payment & Shipping
Payment Methods:
Port of Shipment:
TianJin
Delivery Detail:
7 days
Related Products
-
Johnson Wedge Wire Screen Filter Element Cylinders Filter Cartridge Candle Filter Screen Wedge Wire Drum for Automatic Selfcleaning FilterUS$ 30 - 500MOQ: 10 Pieces -
Johnson Wedge Wire Screen Filter Element Cylinders Filter Cartridge Candle Filter Screen Wedge Wire Drum for Automatic Selfcleaning FilterUS$ 30 - 500MOQ: 10 Pieces
-
DSM Screens for the Starch IndustryUS$ 100 - 1000MOQ: 10 Pieces
-
Stainless Steel Starch Screen With 710 * 1600 *75umUS$ 100 - 1000MOQ: 10 Pieces
-
Stainless Steel Filter Cartridges Wedge Wire FiltrationUS$ 30 - 100MOQ: 10 Pieces
Brand Name
GuangXing
Place of Origin
China
Model Number
GX
Basic Info.
Model NO.
GXLX-12
Name
Stainless Steel Wedge Wire Slot Tube
Diameter
15-1200mm
Slot
0.01-10mm
Length
6m Maximum
Connection
Threading, Welding Ring, Flanges
Transport Package
Wooden Cases
Specification
32mmx1000mmx0.05mm
Trademark
Guangxing
Origin
China
HS Code
8421999
Production Capacity
3000m/Month
Product Description
Slot tubes are welded structures with the support rods in the axial direction of the tube and surface wedge wire around the support rods. They have the unique advantage of very accurate, narrow slot openings and perfect roundness all in one. Slot tubes can be provided with the necessary end pieces for attachments and/or reinforcements.
Normal construction of slot tubes allows for flow out to in filtration. However, flow-in -to-out constructions are also possible.This construction can also be used when the slot tube is used as support tube for another filter medium, so that only the wedge is in contact with the medium to increase the open area.
FEATURES
Back washable wedge wire FOTI tubes
in superior heat resistant pressure welded finish
made of wedge wire profiles connected to support rods
with or without reinforcement (threading, bottoms etc.)
outside diameters 15 to 305 mm
with slots starting from 0.01 mm (in steps of 0.01 mm)
ADVANTAGES
High strength
Good resistance to abrasion and corrosion;
High rigidity;
Good in filtration and fluidity;
Smooth surface;
Fairly well precision and roundness;
Long using life.
Easy to clean and back wash;
Uniform gap.
Application:
Main use as direct filter elements in reversible flow filters and wedge type filters for numerous industries:
Beverage industry
Food Industry
Oil, cooling liquids & fuel filtration
Chemical industry
Water purification
power plants
mechanical engineering
Normal construction of slot tubes allows for flow out to in filtration. However, flow-in -to-out constructions are also possible.This construction can also be used when the slot tube is used as support tube for another filter medium, so that only the wedge is in contact with the medium to increase the open area.
FEATURES
Back washable wedge wire FOTI tubes
in superior heat resistant pressure welded finish
made of wedge wire profiles connected to support rods
with or without reinforcement (threading, bottoms etc.)
outside diameters 15 to 305 mm
with slots starting from 0.01 mm (in steps of 0.01 mm)
ADVANTAGES
High strength
Good resistance to abrasion and corrosion;
High rigidity;
Good in filtration and fluidity;
Smooth surface;
Fairly well precision and roundness;
Long using life.
Easy to clean and back wash;
Uniform gap.
Application:
Main use as direct filter elements in reversible flow filters and wedge type filters for numerous industries:
Beverage industry
Food Industry
Oil, cooling liquids & fuel filtration
Chemical industry
Water purification
power plants
mechanical engineering
| No. | OD(mm) | ID(mm) | Support rod no. | Filter direction |
| 1. | 25.4 | 18.6 | 12 | FOTI |
| 2. | 33 | 24 | 8 | FOTI |
| 3. | 37 | 28 | 8 | FOTI |
| 4. | 38 | 29 | 10 | FOTI |
| 5. | 40 | 31 | 10 | FOTI |
| 6. | 45 | 36 | 12 | FOTI |
| 7. | 48 | 38 | 12 | FOTI |
| 8. | 60 | 51 | 12 | FOTI/FITO |
| 9. | 70 | 61 | 18 | FOTI/FITO |
| 10. | 85 | 76 | 18 | FOTI/FITO |
| 11. | 110 | 101 | 24 | FOTI/FITO |
| 12. | 120 | 111 | 24 | FOTI/FITO |
