Double Layer PPGI Color Steel 5v Roofing Sheet Cold Deck Corrugated Roll Forming Making Machine Factory Price

FOB Price

USD $9000 - $15000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	Zizhuo	Place of Origin	China
Model Number	JR1000	Use	Roof
Certification	CE, SGS	After-sales Service Provided	Engineers available to service machinery overseas
Warranty	18 month	Weight	4600KGS
Dimension(LWH)	8.51.61.65M	Production Capacity	15-20set/month
Condition	New	Voltage	380V 50HZ, 3PHASE
Power(W)	4KW	Type	Tile Forming Machine
Tile Type	Steel

No.	Item		Parameter	Remark
1	Suitable material	Type	Color steel, galvanized steel
		Thickness(mm)	0.35-0.7mm	Test material standard 0.45mm
		Yield strength (Mpa)	≤300mm
		Width (mm)	About 1220mm
2	Forming speed		About 10-15 m/m	Not include cutting time
3	The motor of forming system (kw)		5.5kw	Depends on the final design
4	Hydraulic station power(kw)		4kw	Depends on the final design
5	Voltage requirements		AC380V, 50Hz, 3phase	According to the customer's request
6	Roller material		#45 steel with heat treatment 58-62 degrees
7	Shaft diameter		70mm solid
8	Control system		PLC with touchscreen	Delta brand
