Cnc Rebar Bending Machine From China

cnc rebar bending machine from China

Technical parameter of china cnc rebar bending machine:

Single wire Round steel 4-12mm

Ribbed bar 4-10mm

Double wire Round steel 4-8mm

Ribbed steel bar 4-8mm

Max bending angle ±180°

Center pin diameter 16/18/20

Max towing speed 60m/min

Max bending speed 800°/sec

Dimension 3200*1000*1700mm

Machine color Yellow (customized)

Process piece ≤ 2

Air system pressure ≥ 0.8mpa

Total power 20kw

Work temperature -5℃---40℃

Length accuracy ±1mm

Angle accuracy ±1°

Average power 5kw/h

Weight 1350kg

Description:

1. The automatic stirrup bending machine is used for bending .

2. The automatic stirrup bending machine uses high-quality, fast, energy-saving steel construction process, ensuring efficiency and effective.
3. But also provides the premise for the low price and high quality.
4. widly variety.can produce more than 100 different types wokpiece

Features of China cnc rebar bending machine:

Automatic stirrup bending machine, adopting intelligent control, can process various sizes ,such as square, rectangle, polygon and rhombus etc. At the same time , with straightening and cutting functions, multi-use of one machine.Greatly enhance the production efficiency and reduce labour costs.

Adopting microcomputer control, it has strong functions, high expansibility, Chinese captions, interactive operation and it is easy to study.
Speed is set in sections. The precision of bending tube is high. Multi-angle workpiece is finished at one time.

Besides, assistant pushing, core existing and other functions may also be equipped. And thin-wall pipes are also able to be bended.
Adapted material: round bar, screw rebar,stainless steel, copper pipe, aluminum pipe; articular fittings: particular mould, crease-proof plate, assistant device and so on.
