83XXX Series Single/Three Phase AC Power Source 500VA-150KVA Program Control Variable Frequency AC Power Supply Programmable Laboratory Variable Frequency Converter

83XXX Series Single/Three Phase AC Power Source 500VA-150KVA Program Control Variable Frequency AC Power Supply Programmable Laboratory Variable Frequency Converter thumbnail-1
83XXX Series Single/Three Phase AC Power Source 500VA-150KVA Program Control Variable Frequency AC Power Supply Programmable Laboratory Variable Frequency Converter thumbnail-2
83XXX Series Single/Three Phase AC Power Source 500VA-150KVA Program Control Variable Frequency AC Power Supply Programmable Laboratory Variable Frequency Converter photo-1
83XXX Series Single/Three Phase AC Power Source 500VA-150KVA Program Control Variable Frequency AC Power Supply Programmable Laboratory Variable Frequency Converter photo-2
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
IDI
Place of Origin:
China
Model Number:
83009T,83010T,83015T,83020T,83030T,83045T,83060T,83075T,83090T,83100T,83120T,83150T,83180T,83200T,83250T,83300T
Contact Supplier Request Quote Chat Now
Qingdao Sino Summit Machinery Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name IDI
Place of Origin China
Model Number 83009T,83010T,83015T,83020T,83030T,83045T,83060T,83075T,83090T,83100T,83120T,83150T,83180T,83200T,83250T,83300T
Output Power Other, 9000W-300KW
Output Type Triple
Output Frequency 45-65Hz
Output Voltage 0-300V/500V
Input Voltage 380V

The 83 series Three Phase AC power source adopts digital technology and IGBT intelligent output, pure output wave, with excellent technical performance. The power supply has an anti-shock circuit, suitable for various shock loads such as motors and air conditioners; excellent dynamic characteristics, strong load adaptation, high efficiency, simple operation, cost-efficient, suitable for industries such as export electrical appliances plants, laboratories, defense.


Features

1. Output Capacity: 9000VA-300KVA.

2. Utilize IGBT / PWM technology with switching amplifier design.

3. Adjustable AC output  voltage0-300V/ frequency 45 - 65Hz;

4. Output voltage stability factor can reach 0.5%;

5. Suitable for single and three phase load. Waveform distortion less than 1% on resistance load;

6. Enhanced crest factor. The rate is up to 3:1 at rating current output.

7. Fast recovering time, 2 milliseconds;

8. Unique regulation function in providing capability to turn on high inrush current loads such as motors and compressors.

9. Over-power, short circuit and over temperature protection and alarm;

10. Recall 7 memories. Able to store voltage, frequency and current high limit setting.

11. Other special requirements can be customized.


Technical Specifications

Model 83009T 83015T 83030T 83045T 83060T 83075T 83090T 83100T 83120T 83150T 83180T 83200T
Technical Parameters
Input Voltage/Frequency 380V±10%,50Hz±5%
Output Max. Power Total Power 9KVA 15KVA 30KVA 45KVA 60KVA 75KVA 90KVA 100KVA 120KVA 150KVA 180KVA 200KVA
Single Phase Power 3KVA 5KVA 10KVA 15KVA 20KVA 25KVA 30KVA 33.3KVA 40KVA 50KVA 60KVA 66.6KVA
Output Max. Current     0-150V 27.27A 45.45A 90.90A 136.3A 181.8A 227.2A 272.7A 303.0A 363.6A 454.5A 545.4A 606.0A
0-300V 13.63A 22.72A 45.45A 68.16A 90.90A 113.6A 136.3A 151.5A 181.8A 227.2A 272.7A 303.0A
Phase 3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W  3Ø/4W
Total Harmonic Distortion  (T.H.D)
Crest Factor ≥3
Line Regulation ± 0.1V
Load Regulation ± (0.5% of output +0.5V) at Resistive Load
Response Time
Setting Voltage Range 0.0-300.0V
Resolution 0.1V
Setting Frequency Range 45.0-65.0Hz
Resolution 0.1Hz
Measurement Voltage Range 0.0-300.0V(Phase Voltage);0.0-519.6V(Line Voltage)
Resolution 0.1V
Accuracy ± (0.4% of reading + 0.1% of range)
Measurement Frequency Range 45.0-65.0Hz
Resolution 0.1Hz
Accuracy ±0.1Hz
Measurement Current Range(A) L 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900
M 9.91-27.27 9.91-45.45 9.91-90.90 9.91-99.00 9.91-99.00 9.91-99.00 9.91-99.00 9.91-99.00 9.91-99.00 9.91-99.00 9.91-99.00 9.91-99.00
H - - - 99.1-136.3 99.1-181.8 99.1-227.2 99.1-272.7 99.1-303.0 99.1-363.6 99.1-454.5 99.1-545.4 99.1-606.0
Resolution 0.001A/0.01A/0.1A
Accuracy ± (0.4% of reading + 0.1% of range)
Measurement Power Range(KW) L 0.000-9.000 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900 0.000-9.900
M - 9.90-15.00 9.90-30.00 9.90-55.00 9.90-60.00 9.90-75.00 9.90-90.00 9.90-99.00 9.90-99.00 9.90-99.00 9.90-99.00 9.90-99.00
H - - - - - - - 99.1-100.0 99.1-120.0 99.1-150.0 99.1-180.0 99.1-200.0
Resolution 0.001KW/0.01KW/0.1KW
Accuracy ± (0.4% of reading + 0.1% of range)
Power Factor Range 0.000-1.000
Resolution 0.001
Dimension  W X D X H(mm) 550X800X950 550X800X950 600X1000X1105 650X1200X1155 650X1200X1155 650×1350×1205 800X1500X1255 800X1500X1255 850X1800X1455 850WX2200DX1755H 850WX2200DX1755H 850WX2200DX1755H
General Specifications
Memory 7 memories
Auto Voltage Adjust Enable it for improve voltage regulation within ±0.1V
Efficiency >=80%(at Full Load)
Protection Over Load , Short Circuit , Over Temperature
Calibration Front Panel Calibration
Environment 0-40ºC/20-80%RH
Constant Current Output Standard
Communicating Function RS232(Standard)/RS485(Optional)
PLC Remote(Optional) O/P:ON/OFF


3.Product introduction

Usage

AC Power Source

MOQ

No MOQ

Capacity

100 sets/Month

Package

plywood box

Lead time

15-30 days based on the order quantity

Payment Terms

30% deposit in advance, 70% before shipment

Payment methods

T/T or Western Union

QC

100% inspect before packing, Spot inspect before shipping

After-sale services

24 hours reply and free charge exchange goods

We provide the premium quality products with competitive price for every customer!
