750mm Stainless Steel Hot Rolling Mill GLIMPSE

750mm stainless steel hot rolling mill GLIMPSE

The hot rolling mill is repeatedly rolling the billet to the specified thickness (generally less than 6.0mm) in the metal re-crystallization temperature (generally about 900 ° C), and it is wound into hot rolled steel coils.

The 750mm stainless steel hot rolling machine is the production of hot-rolled stainless steel coils. The thickness of the finished product is 2.4-6.0mm and the width is 480-600mm. The maximum annual output can reach 1 million tons (data depends on the customer's product outline).

The main technical parameters of the 750mm stainless steel hot rolling mill:

Raw materials: 200 series, 300 series, 400 series stainless steel

Blank thickness: 150mm

Blank width: 600mm

Finished product thickness: 2.4-6.0mm

Finished product width: 480-600mm

Inner diameter of steel roll: 530mm

Steel roll outer diameter: maximum 1680mm

Steel roll weight: maximum 10 tons

The process rout of 750mm stainless steel hot rolling mill:

Heating → descaling → rough rolling → fine rolling → coiling

The composition of 750mm stainless steel hot rolling mill:

1) Enter roller table

2) Steel pusher

3) Heating furnace

4) Exit roller table

5) Steel machine

6) Roller table before descaling

7) Descaling vertical mill

8) Descaling box

9) Descaling pump

10) Roller table after descaling

11) Roller table before rough rolling

12) Side guider before rough rolling

13) Rough rolling mill

14) Rough vertical mill

15) Roller table after rough rolling

16) Shear

17) Roller table after shear

18) F1E fine vertical mill

19) Fine two -roller rolling mill (F1)

20) Fine four-roller rolling mill (F2-F9)

21) Electric looper

22) Roller table after fine rolling

21) Side guider before coiler

22) CPC roller table

23) Pinch roller

24) Underground coiler

25) Unload car

750mm stainless steel hot rolling machine layout:

GLIMPSE's scope:

Hot-rolled factory planning and consultation

Design, production and supply, installation and commissioning supervision services

Operation and technical training, technical support
