ER1100
AWS A5.10 ER1100
EN ISO 18273 S Al 1070 (Al99.7)
Description：
ER1100 aluminum wire is designed for applications with electrical conductivity requirements & chemical storage facilities. Excellent corrosion resistance,highest electrical and thermal conductivity.
Used to weld Electrical conductors, chemical storage tanks, piping & tubing for chemicals, refrigeration, food handling equipment, heat exchangers etc.
Welding Position:
Diameters:
0.8mm, 0.9mm, 1.0mm, 1.2mm, 1.6mm.
Typical Mechanical Properties:
Tensile strength(MPa): |
75 |
Yield strength(MPa): |
30 |
Elongation(%): |
-- |
Typical Chemical Compositon:
Si |
Fe |
Cu |
Mn |
Mg |
0.25 |
0.3 |
0.05-0.2 |
0.05 |
|
Cr |
Zn |
Be |
Ti |
Al |
0.05 |
0.1 |
0.0002 |
0.05 |
Min99.0 |
Welding Current:(AC)
Dia:(mm) |
0.8 |
0.9 |
1.0 |
1.2 |
1.6 |
Current/A |
60-170 |
60-170 |
90-210 |
140-260 |
190-350 |
Voltage/V |
13-24 |
13-24 |
15-26 |
20-29 |
25-30 |
Note:
1.Rusty, oil stains, water and other impurity on the weld parts must be cleaned before welding.
2. Shield Gas:100%Ar or 75%Ar+25%He or 50%Ar+50%He
3. In order to get good welding bead, weld on thick plate should be preheat 100-200℃ before welding.
4. Tig rods ER1100 1.6mm, 2.0mm, 2.4mm, 3.2mm available
