MIG 175 Taizhou Supplier Thermally Protected Mig/mag Welder Negotiable Retop Welder Dark Blue Retop Welder IP21S
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1ph Small Co2 Gas Welders Mig 180NegotiableMOQ: 1 -
Excellent Equipment Mig Welding Machine Inverter Portable Welder Mitsushi From Chinese Leading ManufacturersNegotiableMOQ: 1
-
Dual Phase 110/220V IGBT Inverter Mma/mig 2 in 1 Soldadoras Mig Industrial Welding Machine Inverter MIG ARC Welder 15-20l/minNegotiableMOQ: 1
-
MIG-250 Portable Inverter Mig/mag Welding Machine New WheelNegotiableMOQ: 1
-
Hot Sale Weld Inverter Tig/mma Multi-function Welding MachineNegotiableMOQ: 1
Product Description
Features
1. Advanced IGBT technology, energy-efficient and low noise.
2. Digital display, precisely controlled welding current, stable welding process, and excellent welding characteristics.
3. Effective spatter control, improved penetration and better welding effect.
4. Circuit protection against over current, over voltage,and over heat.
5. Built-in wire feeder and adjustable wire feeding speed.
6. Gas/No gas usage optional.
7. Compete with MIG torch, electrode holder, earth clamp, face mask, hammer.
2. Digital display, precisely controlled welding current, stable welding process, and excellent welding characteristics.
3. Effective spatter control, improved penetration and better welding effect.
4. Circuit protection against over current, over voltage,and over heat.
5. Built-in wire feeder and adjustable wire feeding speed.
6. Gas/No gas usage optional.
7. Compete with MIG torch, electrode holder, earth clamp, face mask, hammer.
Technical Specifications
ITEM |
UNIT |
MIG-140TY |
MIG-160TY |
Input Power Voltage |
V |
AC230V±10% |
AC230V±10% |
Input Power Frequency |
Hz |
50/60 |
50/60 |
Rated Input Capacity |
KVA |
3.8 |
4.5 |
Output Current Range (MIG) |
A |
40-140 |
40-160 |
Output Current Range (MMA) |
A |
20-120 |
20-140 |
Load Voltage |
V |
16-21 |
16-22 |
Rated Duty Cycle |
% |
60 |
60 |
Wire Feed Speed |
M/min |
3-15 |
3-15 |
Gas Flow |
L/min |
15-20 |
15-20 |
Dimensions |
MM |
340*140*275 |
340*140*275 |
weight |
Kg |
6.8 |
7 |
Related products
Company Introduction
Certifications
Exhibition
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
