Chinese Factory 40 Amp Mosfet Inverter Air Plasma Cutter CUT-40
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Small 110/220 Volt 180A Igbt Welding Inverter Arc Mma Welder MachineNegotiableMOQ: 1 -
Air Plasma Cutter CUT-50NegotiableMOQ: 1
-
No Used Cnc Plasma Cutting Machine Mini Plasma Cutter Cut 40 Accelerated Test One by One Retop Welder Negotiable 410*155*300 7.8NegotiableMOQ: 1
-
Professional Inverter Portable Plasma Cutter Price.NegotiableMOQ: 1
-
ce Tig Welding MachineNegotiableMOQ: 1
Product Description
Features
1. MOSFET inverter and PWM technology, energy-efficient and low noise.
2. Use compressed air as cutting gas source, cost-effective.
3. Air pressure and cutting current adjustable.
4. Easy operation, narrow cutting seams, smooth cutting performance and less deformation.
5. Circuit protection against over current, over voltage and over heat.
6. Plastic panel, digital display, compact design and easy to carry around.
7. Light industrial applications: production line work; plant maintenance; garage/job shops; fabrication; etc.
2. Use compressed air as cutting gas source, cost-effective.
3. Air pressure and cutting current adjustable.
4. Easy operation, narrow cutting seams, smooth cutting performance and less deformation.
5. Circuit protection against over current, over voltage and over heat.
6. Plastic panel, digital display, compact design and easy to carry around.
7. Light industrial applications: production line work; plant maintenance; garage/job shops; fabrication; etc.
CChinese factory 40 amp Mosfet inverter air plasma cutter CUT-40
Technical Specifications
ITEM |
UNIT |
CUT-30G |
CUT-40G |
CUT-50G |
Input Power Voltage |
V |
AC230V±10% |
AC230V±10% |
AC230V±10% |
Input Power Frequency |
Hz |
50/60 |
50/60 |
50/60 |
Rated Input Capacity |
KVA |
3.5 |
4.8 |
5.2 |
Output Current Range |
A |
10-30 |
10-40 |
10-50 |
No-load Voltage |
250V |
230 |
236 |
245 |
Rated Duty Cycle |
% |
60 |
60 |
60 |
Arc Start |
Touch |
Touch |
Touch |
|
Power Factor |
cosΦ |
0.93 |
0.93 |
0.93 |
Air Pressure |
mpa |
0.2-0.4 |
0.2-0.4 |
0.2-0.4 |
Insulation Grade |
B |
B |
B |
|
Protection Grade |
IP21S |
IP21S |
IP21S |
|
Dimensions |
MM |
420*160*310 |
420*160*310 |
420*160*310 |
weight |
Kg |
7.4 |
7.6 |
7.8 |
Related products
Company Introduction
Certifications
Exhibition
Action now
Why choose Retop?
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
a. We are welding machine MANUFACTURER, so we can offer better price and after-sale service and shorter delivery date.
b. We use all new components,mosfet tube, diode, capacitor and so on imported components.
c. We adopt IGBT technology to decrease failure rate and it is convenient to repair the welding machine and reduce the cost of
repairing, we just need to change the bad pcb board.
d. We provide Warranty period of 1 year for all our items
