Factory Sale hf 200AMP Mosfet Inverter dc Pulse Tig Welder TIG-200M

Factory Sale hf 200AMP Mosfet Inverter dc Pulse Tig Welder TIG-200M photo-1
Factory Sale hf 200AMP Mosfet Inverter dc Pulse Tig Welder TIG-200M photo-2
Factory Sale hf 200AMP Mosfet Inverter dc Pulse Tig Welder TIG-200M photo-3
Factory Sale hf 200AMP Mosfet Inverter dc Pulse Tig Welder TIG-200M photo-4
Factory Sale hf 200AMP Mosfet Inverter dc Pulse Tig Welder TIG-200M photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M

Retop Hot Products

Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M

           CB-40                    MMA-160SI                MIG-185A                TIG-200A



Or please click here for more TIG welder models



Pictures



Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200MFactory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200MFactory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200MFactory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M



Spare parts

Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M



Packing

Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M



Features

(1)Apply MOSFET switching power supply and PWM technology ,HF arc start,easy arc striking,energy-efficient and low noise.

(2)Built-in pulsing functions give you greater control over thin materials.

(3)Thermal and voltage overload protection ensures long life of internal components.

(4)Compact size and lightweight,easy to carry.

(5)Applicable for welding various kinds of metals,such as stainless steel,alloy steel.

(6)Supplied complete with TIG torch,earth clamp,welding cable,face mask and welding brush.



Technical Specifications

ITEM

UNIT

WSM-160

WSM-180

WSM-200

Input power voltage

V

AC220V

AC220V

AC220V

Input power frequency

HZ

50/60

50/60

50/60

Rated input capacity

KVA

3.3

3.9

4.5

Output current range

A

10-160

10-180

10-200

Base current range

A

10-160

10-180

10-200

No-load voltage

V

56

56

56

Pulse frequency

Hz

0.5-200

0.5-200

0.5-200

Downslope time

0-5

0-5

0-5

Arc start



HF

HF

HF

Power factor

cosΦ

0.93

0.93

0.93

Rated duty cycle

%

60

60

60

dimensions

mm

387x160x286

387x160x286

432x203x386

Net weight

kg

8.8

8.8

12.6



Retop Certifications

Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M



Why Choose Retop

1. Supply you top quality products with competitive price under the same quality level,

different products according to your different market demands.



2. Strictly control the whole production process and guarantee punctual delivery, Test each

of our products one by one before packing to ensure the quality.



3. Supply you a good pre-sale, in-sale and after-sale service, We're not just working partners,

but also friends and family.



4. When you come to our factory, we will try our best to supply you all services to make you feel

like at home.



Show room

Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M



Trade Shows

Factory sale hf 200AMP mosfet inverter dc pulse tig welder TIG-200M



FAQ

1.Q:Are you a factory or trading company?

A: We are a factory.



2.Q:Where is your factory located?

A: Our factory is in Wenling, Taizhou city, Zhejiang Province, China.30 mins from Luqiao
Airport by car, 2.5 hours from Ningbo Airport by car, 4 hours from Shanghai Airport by car.



3.Q:What is the material of your products?

A: Taizhou Retop people are always paying great attentions to quality controlling from the
beginning to the end.



4.Q:How about quality control in your factory?

A: Taizhou Retop people are always paying great attentions to quality controlling from the
beginning to the end.



5.Q:How about guarantee?

A: It's within 1 year after goods is discharged in the destination.
