Tig Inverter AC/DC Pulse Welding Machine WSME-200 High Frequency Aluminum Welder
Tig inverter AC/DC pulse welding machine WSME-200 high frequency aluninum welder
Retop Hot Products



CB-40 MMA-160SI MMA-315G MMA-250D
Or please click here for more TIG welder models
Pictures
Spare parts
Packing
Features
(1)Apply MOSFET switching power supply and PWM technology ,energy-efficient and low noise.
(2)Both AC and DC TIG welding available,Mild arc ,easy wire filling and good shaping.
(3)Thermal and voltage overload protection ensures long life internal components.
(4)High-frequency arc starer boosts the current during starting to make striking an arc easier and increase productivity.
(5)Applicable for DC TIG welding of carbon steel, stainless steel,alloy steel,and other non-ferrous metals ,
as well as AC TIG welding of aluminum and aluminum alloy products.
Technical Specifications
|
ITEM |
UNIT |
WSME-200 |
WSME-250 |
WSME-315 |
|
Input power voltage |
V |
AC220V |
AC220V |
AC400V |
|
Input power frequency |
HZ |
50/60 |
50/60 |
50/60 |
|
Rated input capacity |
KVA |
4.6 |
6.4 |
9 |
|
Ac balance control range |
% |
20-80 |
20-80 |
20-80 |
|
Output current range |
A |
200 |
250 |
315 |
|
No-load voltage |
V |
56 |
56 |
56 |
|
Downslope time |
S |
0-5 |
0-5 |
0-5 |
|
Arc start |
|
HF |
HF |
HF |
|
Power factor |
cos |
0.93 |
0.93 |
0.93 |
|
Protection grade |
|
IP21S |
IP21S |
IP21S |
|
Rated duty cycle |
% |
60 |
60 |
60 |
|
dimensions |
mm |
590x345x485 |
590x345x485 |
590x345x485 |
|
Weight |
kg |
23 |
32 |
38 |
Retop Certifications
Why Choose Retop
1. Supply you top quality products with competitive price under the same quality level,
different products according to your different market demands.
2. Strictly control the whole production process and guarantee punctual delivery, Test each
of our products one by one before packing to ensure the quality.
3. Supply you a good pre-sale, in-sale and after-sale service, We're not just working partners,
but also friends and family.
4. When you come to our factory, we will try our best to supply you all services to make you feel
like at home.
Show room
Trade Shows
FAQ
1.Q:Are you a factory or trading company?
A: We are a factory.
2.Q:Where is your factory located?
A: Our factory is in Wenling, Taizhou city, Zhejiang Province, China.30 mins from Luqiao
Airport by car, 2.5 hours from Ningbo Airport by car, 4 hours from Shanghai Airport by car.
3.Q:What is the material of your products?
A: Taizhou Retop people are always paying great attentions to quality controlling from the
beginning to the end.
4.Q:How about quality control in your factory?
A: Taizhou Retop people are always paying great attentions to quality controlling from the
beginning to the end.
5.Q:How about guarantee?
A: It's within 1 year after goods is discharged in the destination.
