Home > Industrial Equipment & Components > Power Transmission Parts > Gearbox > Hangzhou Advance GWH Series Marine Gearbox for Ship Boat
Hangzhou Advance GWH Series Marine Gearbox for Ship Boat
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hangzhou Advance Marine Gearbox MB242NegotiableMOQ: 1 -
Genuine Advance D300A Marine Gearbox for ShipNegotiableMOQ: 1
-
Genuine Advance MB242 Marine Gearbox for ShipNegotiableMOQ: 1
-
Genuine Advance Marine Gearbox MB242 for Marine EngineNegotiableMOQ: 1
-
Advance HC138 Marine Engine Gear Box Gear Ratio1.48:1-4:1NegotiableMOQ: 1
Product Description
Brand new Advance marine gearbox
GW gearboxes have 6 series, each of which has 10 models. The GWC, GWD, GWS and GWH have the function of reverse and reduction, and the GWL and GWK without reversing function. Input and output shafts can be arranged coaxial or offset (vertically, horizontally or diagonally). The gearboxes have adapted to combined design, and all running parts have been carefully designed and machined to the highest standards for less wasted fuel, smooth operation which can be fitted to most engine models. GW series has been approved by the classfication societies such as CCS, BV, ABS, LR, DNV&GL etc.
Detailed Image
GWH–series Marine Gearbox |
||||||||||
Model |
Input Speed
(r/min)
|
Reduction Ratio
(i)
|
Trans. Capacity
(kW/r·min-1)
|
Rated Thrust
(kN)
|
Net Weight
(kg)
|
|||||
GWH28.30 |
400~1800 |
2.00 2.56 3.00 3.57 4.05 |
0.397 |
80 |
1130 |
|||||
GWH30.32 |
400~1800 |
1.97 2.52 2.96 3.52 4.00 |
0.537 |
100 |
1350 |
|||||
GWH32.35 |
400~1800 |
2.00 2.56 3.00 3.57 4.05 |
0.684 |
113 |
2080 |
|||||
GWH36.39 |
400~1800 |
2.03 2.48 2.92 3.48 3.95 |
0.919 |
140 |
2250 |
|||||
GWH39.41 |
400~1600 |
2.00 2.54 2.96 3.50 3.95 |
1.169 |
175 |
2960 |
|||||
GWH42.45 |
400~1600 |
1.97 2.55 2.93 3.58 4.00 |
1.573 |
220 |
3630 |
|||||
GWH45.49 |
400~1400 |
2.03 2.48 3.09 3.48 3.95 |
2.051 |
270 |
4840 |
|||||
GWH49.54 |
400~1200 |
1.97 2.47 3.00 3.52 3.95 |
2.647 |
284 |
7300 |
|||||
GWH52.59 |
400~1200 |
1.97 2.47 3.00 3.52 3.95 |
3.448 |
300 |
8200 |
|||||
GWH60.66 |
400~1200 |
2.00 2.54 2.96 3.50 3.95 |
4.625 |
450 |
14000 |
|||||
GWH66.75 |
300~900 |
1.97 2.47 3.00 3.52 3.95 |
6.99 |
700 |
16500 |
|||||
GWH70.76 |
300~900 |
1.94 2.64 3.00 3.50 3.95 |
8.111 |
750 |
19000 |
|||||
