2018 NEWESTdual chip hash rate 30 mh/s RX560D Graphics Card, 8GB GDDR5

2018 NEWESTdual chip hash rate 30 mh/s RX560 Graphics Card, 8GB GDDR5

The specification acknowledgment of graphics card



Graphics card No.：Dual RX560/8G/GDDR5



The specification acknowledgment of graphics card

Page 2


Product Specification

1. Description of Product：

1.1 Basic Parameter Model Dual RX560/8G/GDDR5 Compliance with EU ROHS standards Yes
PCB
Number of layers 6 Version/Color 1.0/Green Dimension( mm ) 186*102
BIOS
Encapsulation SOIC-8 Type IS25LQ040B-JVLE Version 015.050. 002.001.008088
Chipset
Manufacturer AMD Model RX560D Chip Code Ellsmere Chip Clock（MHz） 1275 Bus width (bit) 256 Process Technology（um） 14nm Max Power ( W ) 80W
Memory
Brand HYNIX/SAMSUNG/ELPIDA/MICRON Dimension 256*32 Type GDDR5 Encapsulation BGA Clock（ns） 7.0 Operating Clock (MHz) 8G Memory Size（MB） 224.0 Bandwidth（GB/s） 256 Total Bus width (BIT) 8



2. Physical Features：

BI(Bus Interface) PCI-E 2.0×1X Power interface 6PIN Output port 0


The specification acknowledgment of graphics card

Page 3


3. Other Parameters： Heat sink/fan Heat sink Color of Heat sink Black Height of baffle /Flanging Optional Distance from the outside of baffle to the golden finger
OS(Operation System) Windows ETH hash rate 30MH/S
