FOR Sapphire NITRO AMD Radeon RX 6700 XT 12G Gaming Graphics Card With 192-bit GDDR6 AMD RX6700XT Graphics Card
- GPU: Boost Clock: Up to 2622 MHz
- Memory: 12GB/192 bit DDR6. 16 Gbps Effective
- Stream Processors: 2560
- RDNA™ 2 Architecture
- Ray Accelerator: 40
| GPU |
AMD Radeon™ RX 6700 XT Graphics Card 7nm GPU AMD RDNA™ 2 Architecture |
| Custom Series | FOR Sapphire NITRO |
| Engine Clock |
Boost Clock: Up to 2622 MHz Game Clock: Up to 2548 MHz Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary. |
| Stream Processors | 2560 |
| Infinity Cache | 96MB |
| Ray Accelerators | 40 |
| Memory Size/Bus | 12GB GDDR6 |
| Displays | Maximum 4 Displays |
| Resolution |
HDMI™: 7680×4320 DisplayPort1.4: 7680×4320 |
| Interface | PCI-Express 4.0 |
| Output |
1x HDMI 3x DisplayPort |
| BIOS Support | Dual UEFI |
| Game Index | 4K |
| Sapphire Features |
Dual BIOS TriXX Software BIOS Switch Premium Digital Power Design Fuse Protection Tri-X Cooling Technology Intelligent Fan Control Precision Fan Control Backplate with ARGB Two-Ball Bearing Fans Hybrid Fan Blade Wave Fin Design V Shape Fin Design for GPU Cooling Integrated Cooling Module TriXX Supported Fan Check Fan Quick Connect TriXX Boost NITRO Glow External RGB LED MB Synchronization |
| AMD Features |
AMD RDNA™ 2 Gaming Architecture DirectX® 12 Ultimate Hardware Raytracing Smart Access Memory Infinity Cache 7nm GPU PCI® Express 4.0 Support AMD FreeSync™ Technology DisplayPort™ 1.4 with DSC HDMI™ 2.1 VRR Video Streaming up to 8K Radeon™ VR Ready Premium AMD FidelityFX Radeon™ Image Sharpening Radeon™ Anti-Lag Radeon™ Software Game Driver Optimizations |
| Cooling | 3 Fans |
| Form Factor |
2.5 slot, ATX Dimension: 310.05(L)X 130.75(W)X 51.4 (H)mm |
| Power Consumption | 260W (Board Power) |
| OS |
Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit operating system required *Does not support all features including but not limited to Hardware Raytracing |
| System Requirement |
Minimum 650 Watt Power Supply 1 x 8-pin + 1 x 6-pin Power Connector. PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended. |
