Help CenterHanDing Optical Automatic Vision Measuring Instrument & Vision Measuring System & HD-432HYT
Related Products
-
H-series Fully-automatic 2.5D Vision Measuring Machine With Laser For Workshop UseCNY 275000 - 278000MOQ: 1 Set -
Multi-sensor Video Measuring Machine CNC Video Measurement MachineCNY 65000 - 68000MOQ: 1 Set
-
High Precision Video Measurement Machine HD-432EYT Automatic Video Measurement Machine SuppliersCNY 75000 - 78000MOQ: 1 Set
-
Optical Equipment Vision Measurement Systems ManufacturerCNY 65000 - 68000MOQ: 1 Set
-
High Quality High Precision Video Measurement MachineCNY 160000 - 168000MOQ: 1 Set
Model |
HD-322HYT |
HD-432HYT |
HD-542HYT |
X/Y/Z measurement range |
300×300×200mm |
400×400×200mm |
500×400×200mm |
XYZ axis base |
Grade 00 green marble |
||
Machine base |
Grade 00 green marble |
||
Bearing capacity of glass countertop |
30kg |
||
Transmission type |
Hiwin linear guide and TBI ground screw UWC servo motor |
||
Optical scale |
High precision optical scale resolution: 0.0005mm |
||
X/Y linear measurement accuracy (μm) |
≤2+L/200 |
≤2.5+L/200 |
≤3+L/200 |
Repetition accuracy (μm) |
≤2 |
≤2.5 |
≤3 |
Camera |
TEO HD color industrial camera |
||
Lens |
Pomeas auto zoom lens, optical magnification: 0.7X-4.5X, image magnification: 30X-200X |
||
Software function and Image system |
Image software: it can measure points, lines, circles, arcs, angles, distances, ellipses, rectangles, continuous curves, tilt corrections, plane corrections, and origin setting. The measurement results display the tolerance value, roundness, straightness, position and perpendicularity. The degree of parallelism can be directly exported and imported into Dxf, Word, Excel, and Spc files for editing which is suitable for batch testing for customer report programming. At the same time, part of and the entire product can be photographed and scanned, and the size and image of the entire product can be recorded and archived, then the dimensional error marked on the picture is clear at a glance. |
||
Image card: SV2000E chip image transmission system, with clear image and stable transmission. | |||
Illumination system |
Continuously adjustable LED light (Surface illumination +contour illumination), with lower heating value and long service life |
||
Overall dimension（L*W*H） |
550×970×1680mm |
700×1130×1680mm |
860×1230×1680mm |
Weight（kg） |
300kg |
350kg |
400kg |
Power supply |
AC220V/50HZ AC110V/60HZ |
||
Computer |
Customized computer host |
||
Display |
Philips 27 inches |
||
Warranty |
1 year warranty for the whole machine |
||
Switching power supply |
Mingwei MW 12V/24V |
||
