Hot sale refrigeration compressor for air dryer
- T/T Credit Card
You May Like
-
130CFM Air compressor refrigerated freeze dryer
-
Air cooled refrigerated compressor air dryer with famous compressor
-
HIROSS 75HP Industrial refrigeration Air Dryer for Air Compressor
-
Air cooling refrigerant air dryer with eco-friendly refrigerant
-
29m3/min Oil Free Air Compressor Used Refrigerated Compressed Air Dryer
-
Refrigerated Air Dryer for Screw Air Compressor
Product Description
Air Cooling Refrigerated Air Dryer for Air Compressor
Inlet Air Temperature: ≤80℃ or 176 ℉
Operating Temperature: ≤40℃ or 104 ℉
Freezing Medium (Refrigerant): R-22
Pressure Dew Point: 2 ~ 10℃ or 35.6 ~ 50 ℉
Offer ISO Standard Air Quality
Type: Air Cooling
Time Proven Design:
Precise design of Copper Tube Heat Exchanger increase the heat exchange areas and efficiently drier high pressure air to standard requested low pressure dew point.
Static Condenser Design: Low Vibration, quiet operation and trouble free.
Energy Saving Design:
Recycle cold Energy from evaporator to heat exchanger, Save power consumption.
Ease of Monitoring:
Electronic(Automatic)Drain Valve.
Safety Protection Systems for frost, overheat and Systems Alarm and Stop for Errors and Overworking. Expand Machine Life.
Best Compressor Brands: Panasonic, Copeland, Taikang.
Model | Capacity (Nm^3/Min | Applicable Air Compressor (HP) | Power Consumption (KW) | Air Entrance Diameter | Unit Size (mm) (L*W*H) | Power | Weight (Kg) |
HR-10AC | 1 | 5 | 0.65 | G1'' | 650*400*600 | 220V/50Hz | 40 |
HR-15AC | 1.5 | 10 | 0.75 | G1'' | 700*400*690 | 220V/50Hz | 48 |
HR-23AC | 2.3 | 15 | 0.85 | G1'' | 700*400*690 | 220V/50Hz | 56 |
HR-28AC | 2.8 | 20 | 1 | G1'' | 780*400*780 | 220V/50Hz | 68 |
HR-38AC | 3.8 | 30 | 1.35 | G1.5'' | 930*500*850 | 220V/50Hz | 125 |
HR-55AC | 5.5 | 40 | 1.4 | G1.5'' | 930*500*850 | 220V/50Hz | 135 |
HR-69AC | 6.9 | 50 | 1.7 | G2'' | 980*540*910 | 220V/50Hz | 158 |
HR-86AC | 8.6 | 60 | 2.1 | G2'' | 980*540*910 | 220V/50Hz | 160 |
HR-110AC | 11 | 75 | 2.6 | G2.5'' | 1080*600*1000 | 220V/50Hz | 198 |
HR-150AC | 15 | 100 | 3.6 | G3'' | 1220*680*1160 | 380V/50Hz | 225 |
HR-180AC | 18 | 125 | 4 | G3'' | 1220*680*1160 | 380V/50Hz | 240 |
HR-220AC | 22 | 150 | 5 | G3'' | 1400*680*1200 | 380V/50Hz | 280 |
HR-250AC | 25 | 175 | 5.3 | G3'' | 1400*680*1240 | 380V/50Hz | 300 |
HR-290AC | 29 | 200 | 5.5 | G4'' | 1600*850*1320 | 380V/50Hz | 350 |
HR-350AC | 35 | 250 | 6 | G4'' | 1600*850*1320 | 380V/50Hz | 380 |
HR-450AC | 45 | 300 | 8.5 | DN100 | 1650*900*1500 | 380V/50Hz | 480 |
HR-550AC | 55 | 350 | 9.5 | DN100 | 1700*1000*1550 | 380V/50Hz | 610 |
HR-650AC | 65 | 400 | 10.5 | DN125 | 2200*1150*1600 | 380V/50Hz | 720 |
About us
1, Hiross is Professional on the business of Air Dryer for Compressed Air for more than ten years.
Equipment & technology
2, Focus on high quality as well as innovation of energy saving technology on air dryers.
Service
3, Stable product quality , supply, the good faith management. Customized as your needs.
Hiross (Zhangzhou) Industrial Machinery Co.,Ltd, has specialized in Compressed Air Drying and Purifying Equipment for more than 15years,is a professional manufacturer engaged in the research, development, production, sale and service of refrigerated air dryer,desiccant air dryer,air filter,air filter element,dehumidifier,and other accessories.
We are located in Zhangzhou City with convenient transportation access,only 1 Hour distance to Xiamen Port. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction.
In recent years, our company has obtained I S O 9 0 0 1,C E,G C C A certificates. Selling well in all cities and provinces around China, Our products are available in 30 countires covering Europe, America, Australia, Asia, Africa, Middle-East, and in countries such as USA, Canada, UK, Mexico, Spain, Serbia,Italy, Finland, Australia, Philippines, Pakistan, Thailand, Indonesia, India,Africa.Our products have been widely used in kinds of industry including petroleum, chemical, electric power, food, medical, biological pharmaceutical,textile industry.We also welcome OEM and ODM orders.
Company Profile
Our company offers variety of products which can meet your multifarious demands. We adhere to the management principles of "quality first, customer first and credit-based" since the establishment of the company and always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from all over the world in order to realize a win-win situation since the trend of economic globalization has developed with anirresistible force.
