Model | Inlet/outlet | Flow rate (m3/min) | Flow rate (m3/h) | Flow rate SCFM | Mears.(mm) | ||||
A | B | C | |||||||
HLT-010 | Rc 1/2" | 1.0 | 60 | 35.3 | 89 | 200 | 141 | ||
HLT-015 | Rc 3/4" | 1.5 | 90 | 52.5 | 89 | 200 | 141 | ||
HLT-018 | Rc 1/2" | 1.8 | 108 | 63.5 | 89 | 233 | 177 | ||
HLT-020 | Rc 3/4" | 2.0 | 120 | 70.6 | 89 | 233 | 177 | ||
HLT-024 | Rc 1" | 2.4 | 144 | 84.7 | 89 | 233 | 177 | ||
HLT-028 | Rc 3/4" | 2.8 | 168 | 98.8 | 120 | 308 | 222 | ||
HLT-036 | Rc 1" | 3.6 | 216 | 127 | 120 | 308 | 222 | ||
HLT-048 | Rc 1" | 4.8 | 288 | 170 | 120 | 407 | 320 | ||
HLT-072 | Rc 1.1/2" | 7.2 | 432 | 254 | 120 | 407 | 320 | ||
HLT-120 | Rc 2" | 12.0 | 720 | 424 | 162 | 496 | 389 | ||
HLT-140 | Rc 2-1/2" | 14.0 | 840 | 494 | L220 | 496 | 389 | ||
HLT-180 | Rc 2" | 18.0 | 1080 | 635 | 160 | 820 | 700 | ||
HLT-220 | Rc 2-1/2" | 22.0 | 1320 | 777 | 160 | 820 | 700 | ||







About us
1, Hiross is Professional on the business of Air Dryer for Compressed Air for more than ten years.

Equipment & technology

Service
3, stable product quality , supply, the good faith management. Customized as your needs.

HIROSS INDUSTRY MACHINERY CO.,ltd have more than 10 years experience in designing,researching and developing and manufacturing the purify,environment friendly,energy saving equipment.Product various from compressed air dryer,dehumidifier,filter,chiller,to accessories,etc.
HIROSS company occupies a 3000 square meter manufacturing field,focus on advanced technology,combining with internationally processing technology to develop and manufacture a series of high performance,low vibration, quiet operation and trouble free equipment.A series of HIROSS products have passed ISO9001,CE,2008 international quality system certification.
We are pleased to welcome you from home or abroad to our company for a visit or a business talk, even if you have already had a familiar partner.
