D210V Mini Metal Lathe for Hobby and Education
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Most Popular 3 in 1 Lathe Drill Mill Combo AT320 Multi Purpose With CE StandardNegotiableMOQ: 1 -
CJM280 38mm Bore Bench Metal Lathe Machine With CENegotiableMOQ: 1
-
AT520 Mini 3 in 1 Combo Lathe Drill Mill Multi Purpose Machine With CENegotiableMOQ: 1
-
BV330 Factory Sale Mini Hobby Lathe Machine With CENegotiableMOQ: 1
-
CY6266 660mm Lathe Machine Heavy Duty With CENegotiableMOQ: 1
Mini Lathe D210V Feature
Precision ground and hardened bed ways.
The spindle is supported with precision roller bearings.
Headstock gears are made of high quality steel, ground and hardened.
Easy operating speed change levers.
Spindle speed range 50-2500rpm.
Easy operating gear box has various feeds and thread cutting function.
With or without cabinet according to requirement.
The spindle is supported with precision roller bearings.
Headstock gears are made of high quality steel, ground and hardened.
Easy operating speed change levers.
Spindle speed range 50-2500rpm.
Easy operating gear box has various feeds and thread cutting function.
With or without cabinet according to requirement.
Specification |
D210V |
Swing ovr bed |
210mm |
Swing over cross slide |
134mm |
Distance between centers |
400mm |
Width of bed |
100mm |
Spindle bore |
21mm |
Spindle taper |
MT3 |
Number of spindle speeds |
Variable |
Range of spindle speeds |
50-2500rpm |
Number of metric threads |
15 |
range of spindle speeds |
0.3-3mm |
Number of imperial threads |
12 |
Range of imperial threads |
10-44 T.P.I |
Range of longitudinal feed |
0.098-0.198mm |
Tool post type |
4 |
Max compoud slide way |
55mm |
Max carriage slide travel |
75mm |
Taistock travel |
60mm |
Tailstock taper |
MT2 |
Main motor |
550KW brushless motor |
Weight |
80kgs |
Dimension |
900X480X450mm |
