Useful 7306 7207 7307 7208 7308 7209 Auto Single Row Angular Contact Ball Bearing
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hot Sale Steering Bearing 776900 Size 11.60*39*204/29mm Angular Contact Ball Bearing For Russia Vaz CarNegotiableMOQ: 1 -
Hot Sale Angular Contact Ball Bearing 3056207 2RS 3207 2RS Size 35*72*27 for UAZ CarNegotiableMOQ: 1
-
7911 7912 7913 7914 7915 7916 Angular Contact Ball BearingNegotiableMOQ: 1
-
7303 7204 7304 7205 7305 7206 Angular Contact Ball BearingNegotiableMOQ: 1
-
7905 7906 7907 7908 7909 7910 Angular Contact Ball BearingNegotiableMOQ: 1
Product name |
7306 7207 7307 7208 7308 7209 Angular contact ball bearing |
Place of Origin |
China |
Brand Name |
VLBG |
Warranty |
24Months |
Certificate |
ISO9001/TS16949 |
Roller body material |
SHX15 |
Row |
Single row |
Tolerance code |
P0 P6 P5 P4 P2 |
Application |
Auto, tractor, machine too, electric machine, water pump, agricultural |
Radial play |
C0, C2, C3, C4,C5 |
What is an Angular Contact Ball Bearing
Angular contact ball bearings have raceways on the inner and outer rings. The inner and outer rings can be relatively displaced along the bearing axis. This type of bearing is particularly suitable for bearing compound loads, that is, loads acting both radially and axially. The axial load-bearing capacity of angular contact ball bearings increases with the contact angle α. The contact angle is the angle between the line of contact points between the ball and the raceway in the radial plane and the vertical line of the bearing axis.
Product Features and Benefits:
High Quality Steel - Ultra clean steel to extend bearing life by up to 80%.
Advanced Grease Technology - NSK lubricants that can extend grease life and performance.
High Grade Balls - Quiet and smooth operation even at high speed.
Super Finished Raceways - Specially honed to minimise noise and improve lubricant distribution and life.
Contact Angle - Offered in 15, 25, 30 and 40 degree angles.
Patented Seals - Provide resistance to contamination in the toughest environments.
Cages - Available in a range of Polyamide, steel and brass cage assemblies.
Quality Assured - 100% testing ensures total product quality.
Angular contact Ball bearings
Angular contact Ball bearings
Single row angular contact ball bearings can only bear axial load in one direction. When bearing radial load, the additional axial force will be caused. And it can only limit the axial displacement of the shaft or housing in one direction. Angular contact ball bearings have a contact angle of 40 degrees to withstand large axial loads. Angular contact ball bearings are of a non-separable design. The shoulders on both sides of the inner and outer rings are different in height. To improve the load capacity of the bearing, the shoulder on one side will be processed lower so that the bearing can be loaded with more steel balls.
Double row angular contact ball bearings can withstand larger radial loads, mainly combined radial and axial loads and moment loads, limiting the axial displacement of the shaft on both sides. The tiltability between the inner and outer rings of the double row angular contact ball bearing is mainly used to limit the bidirectional axial displacement of the shaft and the housing. The allowable tilt angle depends on the internal clearance of the bearing, bearing size, interior design, and acting on it. The force and moment on the bearing and the maximum allowable inclination angle should ensure that no excessive additional stress is generated.
