Home > Industrial Equipment & Components > Bearing > Taper Roller Bearing > 2101-2402025-01 Bearings for Car Automobile Transport Cranes and Loaders Truck Crane Cranes and Loaders Loader Tractor
2101-2402025-01 Bearings for Car Automobile Transport Cranes and Loaders Truck Crane Cranes and Loaders Loader Tractor
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
LM11749/45449 Kit Size 17.462x39.878x13.843 Tapered Roller Bearing Rear Wheel Bearing in StockNegotiableMOQ: 1 -
Vaz 2101-07 Car Use Front Wheel Hub Bearing Kit SS20 21010-3101800-86 7804 7805 With Accessory for SellingNegotiableMOQ: 1
-
VAZ-2121 2123 Front Auto Hub Bearing Kit SS20 21210-3101800-86 32008X 40x68x19 Tapered Roller Bearing for SellingNegotiableMOQ: 1
-
Hot Sale Front Hub Bearing SS20 21010-3101800-86 7804/7805 Kit Tapered Roller Bearing for VAZ 2101-07 a Low PriceNegotiableMOQ: 1
-
Good Quality Front Bearing of the Niva Hub SS20 21210-3101800-86 32008 Kit Tapered Roller Bearing Size 40*68*19 for VAZ 2121NegotiableMOQ: 1
Specification
Product name | 2101-2402025-01 bearings for Car Automobile transport Cranes and Loaders Truck Crane Cranes and Loaders Loader Tractor |
Usage | Single-row Taper Roller Bearing |
Size | 33x62x12 |
Car Make | Car Automobile transport Cranes and Loaders Truck Crane Cranes and Loaders Loader Tractor |
Place of Origin | China |
Brand Name | VLBG |
Model Number | 2101-2402025-01 |
Warranty | 24Months |
Inner diameter | 33MM |
Outside diameter | 62MM |
Height | 12MM |
Bearing type | Friction bearings |
Certificate | ISO9001/TS16949 |
Roller body material | SHX15 |
Weight | 0.211 kg |
Number of rolling bodies | 19 |
Standard | TU 37.006.170-90 |
Roller length | 11.04 |
Type of perceived loads | Radial thrust |
Roller Body diameter | 6.36 |
single-row tapered angular contact roller bearing 2101-2402025-01
Angular contact roller bearing 7707designed for the simultaneous perception of axial and axial loads, which allows you to expand the scope of its application and significantly simplify the design of the supporting units of mechanisms and equipment. In application Angular contact roller bearing 7707 reduces the alignment requirements, which is very important in the production of products, especially large-sized ones. Mounting a single bearing provides the ability to take a radial load together with an axial load acting in one direction (paired installation, with axial bidirectional). Angular contact roller bearing 7707 has a wide range of applications: in general mechanical engineering equipment, in transmissions of tractor and automotive equipment, in wheel hubs, in metalworking machines.
Bearing 7707 (Niva bridge)
Tapered roller bearings, angular contact, single-row. A modification is made with a steel cage (letter Y to the right of the number) or polyamide (letter E is additionally indicated). If a bearing with a polyamide cage is damaged, it is less likely to damage other parts of the car than with a steel one. Contact angle from 10 to 18 °.
In Russia, this type is manufactured at the Volzhsky Bearing Plant (formerly 15 GPPs, products are now labeled VPZ). and also at the Samara Bearing Plant - 9 GPPs.
Bearing 7707, along with bearing 7705, is intended for use only in VAZ cars - "classic" (models 2101, 2102, 2103, 2104, 2105, 2106, 2107) (rear axle) and Niva 2121 4x4 (front and rear axles, differential box) ... Here they are installed in pairs. Another unit where this type is installed is the VAZ 1111 "Oka" differential.
This standard size does not have an exact foreign analogue.
Technical characteristics of the bearing 7707
Inner diameter - 33 mm;
Outside diameter - 62 mm;
Width - 12mm;
Weight - 0.211 kg;
Number of rollers - 19 pcs.;
Roller dimensions - 6.36 / 7.0x11.04 mm;
Dynamic lifting capacity - 76 kN;
Static lifting capacity - 82 kN;
The maximum rated speed is 6300 rpm.
